AGCO NA ST25 tractors Service Manual 79019162 – PDF DOWNLOAD

AGCO NA ST25 tractors Service Manual 79019162 – PDF DOWNLOAD

FILE DETAILS:

AGCO NA ST25 tractors Service Manual 79019162 – PDF DOWNLOAD

Language : English
Pages : 177
Downloadable : Yes
File Type : PDF
Size: 151 MB

DESCRIPTION:

AGCO NA ST25 tractors Service Manual 79019162 – PDF DOWNLOAD

GENERAL PRECAUTIONS FOR SEPARATION
AND RE-INSTALLATION
Before Operation

• Always be safety-conscious in selecting clothes to wear and suitable tools to use. Before disassembly, be sure that you familiarize yourself with the assembled condition for subsequent reference in re-assembly. Keep parts, and tools in proper order during operations. When servicing electrically charged parts, be sure to disconnect the negative battery terminal.
• To prevent oil or water leaks, use the liquid gasket as required. When reassembling disassembled parts, discard used gaskets, 0-rings, or oil seals and install new ones. When lifting tip only the front or rear part of the tractor, be sure to wedge the grounded wheels.
• When the tractor is jacked up, be sure to support the entire tractor with a stand. Lifting it up with jack only is a dangerously unstable procedure. When replacing parts, use authorized genuine Massey Ferguson parts only. Massey Ferguson assumes no responsibility for accidents, operating problems or damage Caused by the use of imitation parts. Also, the use of unauthorized parts will result in relatively poor machine performance.

Precautions To Be Followed When
Installing Standardized Parts
Roller or ball bearings

• When a bearing is installed in a housing by the outer race, use an installer, which is specially designed to push only the outer race and vice versa.
• The installer must be designed to install the bearing on the shaft in a parallel position When installing a bearing which appears the same on both sides, install it so that the face which has the identification number faces in a direction for easy visual identification number faces in direction for easy visual identification.
• All bearings which are to be installed in the transmission case should be placed so that their identification number faces outward. If a shaft or a hole where a bearing is to be installed has an inner seat the bearing should be pushed in completely until it is seated. Bearings should turn smoothly.

TABLE OF CONTENTS:

AGCO NA ST25 tractors Service Manual 79019162 – PDF DOWNLOAD

GENERAL INFORMATION A
ENGINE 8
MAJOR COMPONENTS C
CLUTCH SYSTEM D
TRANSMISSION E
HYDROSTATIC TRANSMISSION F
REAR AXLE AND BRAKES G
FRONT AXLE H
HYDRAULIC SYSTEM J
ELECTRICAL ACCESSORIES K
STEERING SYSTEM L
LUBRICATION & PERIODIC MAINTENANCE M
GENERAL INFORMATION A-2
TRACTOR IDENTIFICATION A-2
Model/Serial Numbers A-2
SPECIFICATIONS A-4
GENERAL PRECAUTIONS FOR SEPARATION AND RE-INSTALLATION A-11
Before Operation A-11
Precautions To Be Followed When Installing Standardized Parts

IMAGES PREVIEW OF THE MANUAL:
