Ammann ARX 36-2 ARX 40-2 ARX 45-2 Tandem Roller Operating Manual - PDF

Ammann ARX 36-2 ARX 40-2 ARX 45-2 Tandem Roller Kubota V2403-M-E3B EU Stage IIIA / US EPA Tier 4i Operating Manual – PDF DOWNLOAD

FILE DETAILS:

Ammann ARX 36-2 ARX 40-2 ARX 45-2 Tandem Roller Kubota V2403-M-E3B EU Stage IIIA / US EPA Tier 4i Operating Manual – PDF DOWNLOAD

Language : English
Pages : 178
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:



TABLE OF CONTENTS:

Ammann ARX 36-2 ARX 40-2 ARX 45-2 Tandem Roller Kubota V2403-M-E3B EU Stage IIIA / US EPA Tier 4i Operating Manual – PDF DOWNLOAD

Contents 8

1 SPECIFICATION MANUAL 13

1 1Basic data 14

1 2Dimensional drawing of the machine 16

1 3Technical data 18

2 OPERATING MANUAL 23

2 1Main safety precautions 25

2 1 1Safety precautions during operation of the machine 25

2 1 1 1Before compacting works are started 25

2 1 1 2Work in the dangerous area 25

2 1 1 3Ensurance of safety measures by the provider 26

2 1 1 4 Protective frame ROPS 26

2 1 2Requirements for the qualification of machine operators 27

2 1 3Driver’s obligations 28

2 1 4Forbidden activities – safety and guarantee 29

2 1 5Safety notices and signs applied on the machine 31

2 1 6Manual signals 35

2 2Environmental and hygiene principles 38

2 2 1Hygiene principles 38

2 2 2Environmental principles 38

2 3Preservation and storage 39

2 3 1Short-term preservation and storage for 1–2 months 39

2 3 2Preservation and storage of the machine for a period over 2 months 39

2 3 3Machine depreservation 40

2 4Machine disposal after its service life 41

2 5Machine description 42

2 6Controls and checking instruments 44

2 6 1Dashboard and control panels 45

2 7Machine operation and use 60

2 7 1Starting the engine 61

2 7 2Drive and reverse drive 65

2 7 3Stopping the machine and turning off the engine 71

2 7 4Machine emergency stop 71

2 7 5Machine parking 73

2 7 6Panic response 73

2 7 7Sprinkling 75

2 7 8ACE Force (optional equipment) 75

2 7 9Infrathermometer (optional) 76

2 7 10ROPS lifting and lowering 82

2 7 11Telematics readiness 85

2 7 12Edge cutter (optional equipment) 86

2 8Machine transport 88

2 8 1Loading the machine 89

2 8 1 1Loading the machine using a ramp 89

2 8 1 2Loading the machine using a crane 90

2 9Special conditions to use the machine 91

2 9 1Towing the machine 91

2 9 2Drum offset 93

2 9 3Machine operation during initial run period 94

2 9 4Machine operation at low temperatures 94

2 9 5Machine operation at higher temperatures and humidity 94

2 9 6Machine operation at higher altitudes 94

2 9 7Machine operation in dusty environment 95

2 9 8Driving with vibration on compacted and hard materials 95

3 MAINTENANCE MANUAL 97

3 1Safety and other measures during maintenance of the machine 99

3 1 1Safety during machine maintenance 99

3 1 2Fire protection when operating fluids are changed 99

3 1 3Environmental and hygiene principles 100

3 2Specification of operating fluids 101

3 2 1Engine oil 101

3 2 2Fuel 102

3 2 3Coolant 103

3 2 4Hydraulic oil 104

3 2 5Lubricating grease 104

3 2 6Emulsion 104

3 3Fluids 105

3 4Lubrication and maintenance chart 106

3 5Lubrication and service plan 108

3 6Lubrication and maintenance operations 109

Every 20 hours of operation (daily) 110

3 6 1Fuel check 110

3 6 2Checking the oil in the engine 111

3 6 3Engine coolant check 112

3 6 4Checking the oil in the hydraulic tank 113

3 6 5Cleaning the hydraulic oil cooler 114

3 6 6Air filter check 115

3 6 7Check of the sprinkling emulsion level 116

3 6 8Sprinkling tank refilling 117

3 6 9Scraper adjustment 117

3 6 10Check of warning and checking devices 118

3 6 11Engine tightness check 120

3 6 12Checking the fan and engine belt for condition 121

Every 50 hours of operation 122

3 6 13Check of hoses and clips 122

3 6 14Travel pressure check 123

3 6 15Battery check 124

Every 100 hours of operation (weekly) 125

3 6 16Air filter cleaning 125

3 6 17Cleaning the water separator on the fuel filter 126

3 6 18Machinze lubrication 127

3 6 19Tyre pressure check 128

Every 250 hours of operation (every 3 months) 129

3 6 20Fuel filter replacement 129

3 6 21Engine oil change 130

3 6 22Checking the hoses of the engine cooler for wear and mounting 132

3 6 23Checking the mounting of hoses and clips 132

3 6 24Sprinkling filter cleaning 133

3 6 25Checking the intake piping of the engine 134

Every 500 hours of operation (every 6 months) 135

3 6 26Fuel tank cleaning 135

3 6 27Electrical installation check 136

3 6 28Replacement of the fuel separator filter cartridge 136

3 6 29Valve clearance check and adjustment 137

3 6 30Engine cooler cleaning 137

3 6 31Check of rubber-metal elements of the engine cooler 138

Every 1000 hours of operation (yearly) 139

3 6 32Hydraulic oil and filter change 139

3 6 33Air filter cartridges replacement 141

3 6 34Damping system check 143

3 6 35Swinging support check 143

3 6 36Articulation joint check 144

Every 2000 hours of operation (every 2 years) 145

3 6 37Engine belt replacement 145

3 6 38Engine coolant change 145

3 6 39Replacement of hoses of the cooling system 147

3 6 40Replacement of rubber-metal elements of the engine cooler 147

3 6 41Replacement of hoses of the fuel system 148

3 6 42Replacement of suction hoses 148

Maintenance as required 149

3 6 43Gas strut replacement 149

3 6 44Cleaning the water separator 150

3 6 45Cleaning the water tank 150

3 6 46Cleaning the machine 151

3 6 47Draining water from the sprinkling circuit before the winter season 152

3 6 48Fuel system venting 153

3 6 49Checking the screw connections for tightening 154

3 7Troubleshooting 156

3 7 1List of error codes displayed on the display 156

3 8Appendices 162

Wiring diagram 162

Hydraulic diagram ARX 36-2, ARX 40-2, ARX 45-2 168

Hydraulic diagram ARX 36-2C, ARX 45-2C 170

Hydraulic diagram – Edge cutter 172

Table of spare parts for regular maintenance 174

Content of the filter set after 250 hours (4-760215) 175

Content of the filter set after 500 hours (4-760219) 175

Content of the filter set after 1,000 hours (4-760216) 175
