Ammann ARX 36-2 Tandem Roller Parts Catalogue Manual 5952001 - PDF DOWNLOAD

Ammann ARX 36-2 Tandem Roller Kubota V2403-M-E3B EU Stage IIIA / U.S. EPA Tier 4i Parts Catalogue Manual SN 5952001 – PDF DOWNLOAD

FILE DETAILS:

Ammann ARX 36-2 Tandem Roller Kubota V2403-M-E3B EU Stage IIIA / U.S. EPA Tier 4i Parts Catalogue Manual SN 5952001 – PDF DOWNLOAD

Language : English
Pages : 240
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

Ammann ARX 36-2 Tandem Roller Kubota V2403-M-E3B EU Stage IIIA / U.S. EPA Tier 4i Parts Catalogue Manual SN 5952001 – PDF DOWNLOAD

ARX 36-2 1
Preface 3
Table of contens 7
Spare parts catalogue 13
001 ARX36-2 01 Engine 16
001-010 Engine part A 18
001-010-003 Hydraulic pump 20
001-010-004 Holder relays 22
001-020 Engine part B 24
001-020-002 Cooler 28
001-020-007 Engine – oil drain 32
002 ARX36-2 02 Drive 34
002-010 Drum 36
002-090 Fixed scraper 42
002-090-001 Spraying system scraper 44
002-090-002 Internal scraper 46
003 ARX36-2 03 Frame 48
003-010 Chassis front 50
003-010-003 Hydraulic oil tank 54
003-010-004 Fuel tank 56
003-011 Fuel tank filter 58
003-020 Frame rear 60
003-020-009 Tread 64
003-020-010 Water tank 66
003-020-011 Cooler 68
003-020-012 Holder steering cylinder 70
003-020-014 Pressurized sprinkling system 72
003-030 Hood green 74
003-030-001 Cover hood Ammann 76
003-032 Customer hood 78
003-032-001 Customer hood 80
003-035 Execution without lighting 82
003-040 Operator stand 84
003-040-001 Operator stand 88
003-060 Driver’s seat Ammann 92
003-110 Folding ROPS 94
004 ARX36-2 04 Joint 96
004-010 Pendulum joint 98
004-010-001 Pendulum joint 100
004-010-002 Pendulum support 102
004-030 Steering cylinder 104
005 ARX36-2 05 Hydraulic 106
005-010 Make without lock 108
005-020 Differential lock 110
005-050 Brake valve block 112
005-060 Vibration control valve 114
005-070 Hose set part A 116
005-070 Hose set part B 118
005-080 Hose set – Drum front 120
005-090 Hose set – Drum rear 122
006 ARX36-2 06 Electrical installation 124
006-010 Instrument panel 126
006-020 Switch cabinet 128
006-020-001 Switch cabinet 130
006-030 Battery 132
006-040 Operating lever 134
006-050 Signal horn 136
006-070 Looms of wires 138
006-070-001 Looms of wires 140
006-070-001-001 Looms of wires 142
006-070-001-002 Looms of wires 144
007 ARX36-2 07 Basic equipment 146
007-010 Signs 148
007-020 Type plate – AMMANN 150
007-021 Type plate 152
008 ARX36-2 08 Option 154
008-010 Road lights 156
008-015 Road lights and turn signal 158
008-015-005 Front headlamps 160
008-015-006 Rear lamps 162
008-030 Without additional light beacon 164
008-035 Additional lights lighthouse 166
008-040 Warning light ROPS 168
008-042 Warning beacon green 170
008-045 Warning light constantly shining 172
008-050 Reversing alarm 174
008-065 Retainer license number plate 176
008-075 Rear mirror 178
008-080 Left control lever 180
008-090 Seat heating 182
008-100 Armrests 184
008-110 Roof 186
008-115 Warning light for roof 188
008-120 Lockable ROPS 190
008-130 Wire anti-loose 192
008-140 Brake buzzer 194
008-150 Tank cap option 196
008-155 Infrared thermometer 198
008-160 Edge cutter part A 200
008-160 Edge cutter part B 204
008-160-035 Hoses for edge cutter KSG 206
008-190 Scraper collapsible 208
008-190-001 Scraper sprinkling foldable 210
008-190-002 Scraper internal folding 212
008-200 Filter set 250 h 214
008-210 Filter set 500 h 216
008-220 Filter set 1000 h 218
008-280 ACE Force 220
008-300 Retractor belt 3″ 222
008-310 Track unit 224
Index 227
