Ammann AV 70 X Tandem Roller Parts Manual 4062129 - PDF

Ammann AV 70 X Articulated Tandem Roller Cummins Tier 3 Parts Manual 4062129 – PDF DOWNLOAD

FILE DETAILS:

Ammann AV 70 X Articulated Tandem Roller Cummins Tier 3 Parts Manual 4062129 – PDF DOWNLOAD

Language : English
Pages : 302
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:


TABLE OF CONTENTS:

Ammann AV 70 X Articulated Tandem Roller Cummins Tier 3 Parts Manual 4062129 – PDF DOWNLOAD

AV 70 X........................................................  1
	Preface....................................................  5
	Table of contens...........................................  9
	Spare parts catalogue...................................... 15
		001 AV 70 X Engine..................................... 18
			001-104 Engine..................................... 20
				001-104-013 Contactor.......................... 24
			001-124 Cooling system............................. 26
			001-126 Protective grid............................ 30
			001-134 Intake and exhaust pipe.................... 32
			001-221 Engine controls............................ 34
			001-284 Pump group................................. 36
		002 AV 70 X Drive...................................... 38
			002-001 Drum....................................... 40
				002-001-002 Left cover......................... 42
				002-001-003 Right cover........................ 44
			002-010 Yoke....................................... 46
			002-021 Vibrator................................... 48
			002-030 Drum drive................................. 50
			002-031 Hub drum assembly.......................... 52
			002-217 Tread...................................... 54
			002-470 Speed sensor............................... 56
		003 AV 70 X Frame...................................... 58
			003-045 Lower fixed scraper........................ 60
			003-046 Upper fixed scraper........................ 62
			003-051 Frame front................................ 64
			003-061 Frame rear................................. 66
			003-065 Steering joint............................. 68
				003-065-001 Swivel............................. 72
			003-090 Tank cap................................... 74
			003-093 Water tank................................. 76
			003-094 Spraying................................... 78
			003-096 Spraydown pipe............................. 80
			003-196 Ventilation grid........................... 82
			003-207 Cover...................................... 84
			003-250 Fuel tank.................................. 86
			003-461 Battery mounting........................... 88
			003-630 Tread...................................... 90
		004 AV 70 X Cab........................................ 92
			004-155 Operator platform.......................... 94
			004-165 Cab part A................................. 98
				004-165-011 Ventilator.........................104
			004-165 Cab part B.................................106
			004-165 Cab part C.................................110
				004-165-001 Roof...............................114
			004-170 Cab bedding................................116
			004-185 Control....................................118
				004-185-001 Travel controls....................120
				004-185-007 Complete seat......................124
					004-185-007-001 Cab seat...................126
					004-185-007-002 Platform seat..............128
			004-200 Cover hood.................................130
			004-525 Lifting arm - cab..........................134
			004-601 Heating....................................136
				004-601-001 Housing............................138
		005 AV 70 X Hydraulic..................................140
			005-300 Front drum hydraulic system................142
			005-303 Front drum hydraulic equipment w/o lock....144
			005-310 Rear drum hydraulic system.................146
			005-313 Rear drum hydraulic equipment w/o lock.....148
			005-335 Hydraulic..................................150
			005-350 Pump hydraulics............................152
			005-358 Cube.......................................156
				005-358-001 Cube...............................158
			005-361 Hydraulic oil tank.........................160
			005-364 Steering hydraulics........................162
			005-370 Cooling hydraulics.........................164
			005-385 Lifting hydraulics.........................166
		006 AV 70 X Electrical installation....................168
			006-408 Electrical installation....................170
				006-408-001 Instrument panel...................174
				006-408-002 Instrument panel...................176
				006-408-003 Screed.............................180
			006-410 Cab wiring.................................182
			006-428 Display unit AMMANN........................184
		007 AV 70 X Basic equipment............................186
			007-510 Signs......................................188
			007-511 Cover......................................190
			007-515 Plate......................................192
		008 AV 70 X Option.....................................194
			008-055 Lower tilting scraper......................196
			008-056 Upper tilting scraper......................198
			008-091 Tank cap...................................200
			008-180 Railing....................................202
			008-181 Roof.......................................204
			008-183 Equipment cover............................206
			008-188 Railing....................................208
				008-188-001 Folding box........................210
			008-189 Roof.......................................212
			008-190 Rear mirror................................214
			008-191 Windscreen wiper rear......................216
				008-191-001 Electrical system..................218
			008-216 Tread......................................220
			008-411 Platform wiring............................222
			008-413 Warning light - cab........................224
			008-414 Warning light - operator platform..........226
			008-415 Reversing alarm............................228
			008-416 Auxiliary headlamps - cab..................230
			008-417 Auxiliary headlamps - operator platform....232
			008-418 Auxiliary headlamps - operator platform....234
			008-424 Registration plate lighting................236
			008-438 Module Telematic...........................238
			008-439 Prepairing Telematic.......................240
			008-440 Car radio..................................242
			008-520 Tool kit...................................244
			008-522 Attachment parts...........................246
			008-524 Belt guard.................................248
			008-527 Lifting arm - platform.....................250
			008-541 Set of spare parts.........................252
			008-546 Service kit 500 EH.........................254
			008-550 Edge cutter................................256
				008-550-001 Edge cutter........................258
					008-550-001-003 Hub........................262
					008-550-001-004 Roller.....................264
				008-550-002 Edge cutter hydraulics.............266
				008-550-003 Cutter control wiring..............268
			008-555 Thermometer................................270
			008-591 Fan cover..................................272
			008-615 Air conditioning system....................274
				008-615-006 Electrical installation............278
			008-625 Fire extinguisher..........................280
			008-695 Retractor belt.............................282
	Index......................................................285
