Ammann STV 3500 E sn 3104156 - AFT 400-3 sn AN3034627 Parts Manual - PDF

Ammann STV 3500 E s/n 3104156 – AFT 400-3 s/n AN3034627 Parts Catalogue Manual – PDF DOWNLOAD

FILE DETAILS:

Ammann STV 3500 E s/n 3104156 – AFT 400-3 s/n AN3034627 Parts Catalogue Manual – PDF DOWNLOAD

Language : English
Pages : 407
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

Ammann STV 3500 E s/n 3104156 – AFT 400-3 s/n AN3034627 Parts Catalogue Manual – PDF DOWNLOAD

Service, repair and wear part kits – TV-E
Wear part and Inspection kits – TV-E 1
Plate / bars KITS
40-4812066016 Screed plates, H500 2
40-4812017384 Wear part kit tamper bar, wear plate 3
40-4812063762 Wear part kit screed plates, tamper bar 4
40-4812063751 Wear part kit heating rod, with plug 5
40-4812063792 Renewal kit (heating rod, with plug) 6
Heating Element KITS
40-4812063751 Wear part kit heating rod, with plug See page 5
Bearing KITS
40-4812076937 Bearing kit tamper drive 8
40-4812076940 Bearing kit tamper wing 9
Guide plate KITS
40-4812061203 Kit, guide plate 10
Mechanical Basic screed
40-4812074056 Basic screed 11
Extension unit, l.h.
40-4812074050 Extension unit, l.h. 18
Extension unit, r.h.
40-4812074053 Extension unit, r.h. 19
Hose guide, centre
40-4812015267 Hose guide, centre 20
Hose guide, l.h.
40-4812015308 Hose guide, l.h. 21
Hose guide, r.h.
40-4812015314 Hose guide, r.h. 22
Hose guide
40-4812024018 Hose guide 23
Hose clamp
40-4812015344 Hose clamp 24
Scale, l.h.
40-4812019348 Scale, l.h. 25
Scale, r.h.
40-4812019350 Scale, r.h. 26
Hydraulic, cylinder
40-4812018173 Hydraulic, cylinder 27
Electric heating, cpl., V3500TV-E
40-4812201679 Electric heating, cpl. 29
Footboard
40-4812017123 Footboard – From S/N 3102015 ff. 33
Footplate
40-4812017105 Footplate 36
Footplate middle
40-4812017137 Footplate middle 37
Footplate side
40-4812018361 Footplate side 39
40-4812018215 Roof profile, with hyd., V / TV, plc
40-4812018215 Profile adjustment 40
Cable sensor
40-4812118180 Cable sensor 43
Hood
40-4812024955 Hood 44
Hood, r.h.
40-4812024796 Hood, r. h. 45
Hood, l.h.
40-4812062283 Hood, l.h. 46
Hydr. profile adjustment
40-4812229613A Hydr. profile adjustment 47
Roof profile
40-4812018247 Roof profile 48
Drive shaft
40-4812012496 Drive shaft 50
Carrier
40-4812018249 Carrier, l.h. 51
40-4812018250 Carrier, r.h. 53
Top con rod, back cpl.
40-4812018367 Top con rod, back 55
Top con rod, back
40-4812018201 Top con rod, back 56
40-4812018202 Top con rod, back 57
Track adjuster
40-4812018291 Track adjuster 58
Operation width
Basic operation width
40-4812013677 Basic operation width 59
Material duct
40-4812012768 Material duct, l.h. 60
40-4812012770 Material duct, r.h. 61
Operation width 4,1m, 295 TV E
40-4812073466 Operation width 4,1m, 295 TV E 62
Extension mount AT300 TV E, l.h.
40-4812073316 Extension mount AT300 TV E, l.h. 63
Hood
40-4812016982 Hood 66
Electric heating, AT300
40-4812014141 Electric heating, AT300 67
Tamper drive, l.h.
40-4812073311 Tamper drive , l.h. 69
Tamper drive, l.h.
40-4812073310 Tamper drive , l.h. 71
Footplate
40-4812018503 Footplate 73
Vibration
40-4812073315 Vibration 74
Electric, extension mount
40-4812018013 Electric 76
Housing ATL
40-4812017963 Housing ATL 77
Harness
40-4812012881 Harness W6 78
Extension mount AT300 TV E, r.h.
40-4812073317 Extension mount AT300 TV E, r.h. 79
Hood
40-4812016982 Hood See page 66
Electric heating, AT300
40-4812014141 Electric heating, AT300 See page 67
Tamper drive, r.h.
40-4812073313 Tamper drive, r.h. 84
Tamper drive, r.h.
40-4812073312 Tamper drive, r.h. 86
Footplate
40-4812018503 Footplate See page 73
Vibration
40-4812073315 Vibration See page 74
Electric, extension mount
40-4812018026 Electric 90
Housing ATL
40-4812017964 Housing ATR 91
Harness
40-4812012882 Harness W7 92
Material duct, l.h.
40-4812215298 Material duct, l.h. 93
Material duct, r.h.
40-4812215309 Material duct, r.h. 94
Available operation width Operation width 4,7m, 295 TV E
40-4812073470 Operation width 4,7m, 295 TV E 95
Extension mount AT300 TV E, l.h.
40-4812073316 Extension mount AT300 TV E, l.h. See page 63
Hood
40-4812016982 Hood See page 66
Electric heating, AT300
40-4812014141 Electric heating, AT300 See page 67
Tamper drive, l.h.
40-4812073311 Tamper drive , l.h. See page 69
Tamper drive, l.h.
40-4812073310 Tamper drive , l.h. See page 71
Footplate
40-4812018503 Footplate See page 73
Vibration
40-4812073315 Vibration See page 74
Electric, extension mount
40-4812018013 Electric See page 76
Housing ATL
40-4812017963 Housing ATL See page 77
Harness
40-4812012881 Harness W6 See page 78
Extension mount AT300, TV E r.h.
40-4812073317 Extension mount AT300 TV E, r.h. See page 79
Hood
40-4812016982 Hood See page 66
Electric heating, AT300
40-4812014141 Electric heating, AT300 See page 67
Tamper drive, r.h.
40-4812073313 Tamper drive, r.h. See page 84
Tamper drive, r.h.
40-4812073312 Tamper drive, r.h. See page 86
Footplate
40-4812018503 Footplate See page 73
Vibration
40-4812073315 Vibration See page 74
Electric, extension mount
40-4812018026 Electric See page 90
Housing ATL
40-4812017964 Housing ATR See page 91
Harness
40-4812012882 Harness W7 See page 92
Material duct, l.h.
40-4812215298 Material duct, l.h. See page 93
Material duct, r.h.
40-4812215309 Material duct, r.h. See page 94
Operation width 4,1m, 295 V E
40-4812073464 Operation width 4,1m, 295 V E 114
Extension mount AT300 V E, l.h.
40-4812073320 Extension mount AT300 V E, l.h. 115
Hood
40-4812016982 Hood See page 66
Electric heating, AT300
40-4812014247 Electric heating, AT300 119
Plate, l.h.
40-4812014578 Plate, l.h. 121
Footplate
40-4812018503 Footplate See page 73
Vibration
40-4812073315 Vibration See page 74
Electric, extension mount
40-4812018013 Electric See page 76
Housing ATL
40-4812017963 Housing ATL See page 77
Harness
40-4812012881 Harness W6 See page 78
Extension mount AT300 V E, r.h.
40-4812073321 Extension mount AT300 V E, r.h. 126
Hood
40-4812016982 Hood See page 66
Electric heating, AT300
40-4812014247 Electric heating, AT300 See page 119
Plate, r.h.
40-4812014573 Plate, r.h. 131
Footplate
40-4812018503 Footplate See page 73
Vibration
40-4812073315 Vibration See page 74
Electric, extension mount
40-4812018026 Electric See page 90
Housing ATR
40-4812017964 Housing ATR See page 91
Harness
40-4812012882 Harness W7 See page 92
Material duct, l.h.
40-4812215298 Material duct, l.h. See page 93
Material duct, r.h.
40-4812215309 Material duct, r.h. See page 94
Operation width 4,7m, 295 V E
40-4812073468 Operation width 4,7m, 295 V E 138
Extension mount AT300 V E, l.h.
40-4812073320 Extension mount AT300 V E, l.h. See page 115
Hood
40-4812016982 Hood See page 66
Electric heating, AT300
40-4812014247 Electric heating, AT300 See page 119
Plate, l.h.
40-4812014578 Plate, l.h. See page 121
Footplate
40-4812018503 Footplate See page 73
Vibration
40-4812073315 Vibration See page 74
Electric, extension mount
40-4812018013 Electric See page 76
Housing ATL
40-4812017963 Housing ATL See page 77
Harness
40-4812012881 Harness W6 See page 78
Extension mount AT300 V E, r.h.
40-4812073321 Extension mount AT300 V E, r.h. See page 126
Hood
40-4812016982 Hood See page 66
Electric heating, AT300
40-4812014247 Electric heating, AT300 See page 119
Plate, r.h.
40-4812014573 Plate, r.h. See page 131
Footplate
40-4812018503 Footplate See page 73
Vibration
40-4812073315 Vibration See page 74
Electric, extension mount
40-4812018026 Electric See page 90
Housing ATR
40-4812017964 Housing ATR See page 91
Harness
40-4812012882 Harness W7 See page 92
Material duct, l.h.
40-4812215298 Material duct, l.h. See page 93
Material duct, r.h.
40-4812215309 Material duct, r.h. See page 94
Conversion KIT for old extension
40-4812078605 Conversion kit BoWex® – coupling
40-4812078605 Conversion kit BoWex® – coupling 157
Conversion kit, Vibration VT l.h.
40-4812078682 Conversion kit, Vibration VT l.h. 158
Conversion kit, Vibration VT r.h.
40-4812078684 Conversion kit, Vibration VT r.h. 160
40-4812017743 Connection cable, PLC
40-4812017743 Electric W17 162
Protection and trim plates, TV, TV – E
40-4812200921A Protection and trim plates, TV 163
Kit, hood
40-4812023730 Kit, hood 165
Hood extension, l.h.
40-4812016884 Hood extension, l.h. 166
Hood extension, r.h.
40-4812016857 Hood extension, r.h. 167
Kit, guide plate
40-4812061203 Kit, guide plate See page 10
Screed plates, V3500TV-E
40-4812066016 Screed plates, H500 See page 2
Tamper
40-4812073456 Tamper drive 170
Kit, tamper subassembly
40-4812073453 Kit, tamper subassembly 171
Tamper drive MT, l.h.
40-4812073764 Tamper drive middle, l.h 172
Tamper drive MT, r.h.
40-4812073782 Tamper drive middle, r.h 174
Tamper drive VT, l.h.
40-4812073408 Tamper drive VT, l.h 176
Tamper drive VT, r.h.
40-4812073400 Tamper drive VT, r.h 178
Tamper drive MT, l.h.
40-4812013581 Tamper drive middle, l.h. 180
Tamper drive MT, r.h.
40-4812013582 Tamper drive middle, r.h. 181
Tamper drive VT, l.h.
40-4812013583 Tamper drive extension, l.h. 182
Tamper drive VT, r.h.
40-4812013584 Tamper drive extension, r.h. 184
Hydrl. tamper
40-4812201819 Hydraulic, tamper 186
Vibration
40-4812073462 Vibration 189
Kit, vibration
40-4812073461 Kit, vibration 191
Vibration midde, l.h.
40-4812014325A Vibration middle, l.h. 192
Vibration midde, r.h.
40-4812014344A Vibration middle, r.h. 194
Vibration VT, l.h
40-4812073457 Vibration VT, l.h 196
Vibration VT, r.h
40-4812073459 Vibration VT, r.h 198
Hydrl. vibration
40-4812018147 Hydraulic, vibration 200
Electric system, V / TV – E, PLC
40-4812217463 Electric V3500 TV E PLC 203
Electric
40-4812072003 Electric 204
Terminal box
40-4812076381 Terminal box 205
Harness
40-4812071970 Harness W1 215
40-4812072004 Harness W2 217
40-4812072005 Harness W3 219
Electric, side shield
40-4812071834 Electric, side shield 220
Electric, side shield
40-4812018843 Electric, side shield 221
Blind plug
40-4812071964 Blind plug 223
Harness
40-4812018845 Harness W4 224
40-4812018846 Harness W4.1 225
40-4812018847 Harness W4.2 226
40-4812018848 Harness W4.3 227
40-4812018849 Harness W4.4 228
40-4812018853 Harness W4.8 229
40-4812018854 Harness W5 230
40-4812018855 Harness W5.1 231
40-4812018856 Harness W5.2 232
40-4812018857 Harness W5.3 233
40-4812018858 Harness W5.4 234
40-4812018862 Harness W5.8 235
40-4812072825 Harness W15.5 236
40-4812072826 Harness W16.5 237
Mounting parts, side shield
40-4812071848 Mounting parts, side shield 238
Electric, heating
40-4812072011 Electric, heating 240
Housing
40-4812017937 Housing MTL 241
40-4812017938 Housing MTR 242
40-4812017939 Housing VTR 243
40-4812017940 Housing VTL 245
Resistance thermometer cpl.
40-4812042276 Resistance thermometer cpl. 247
Wiring
40-4812071846 Wiring 248
Harness
40-4812071970 Harness W1 See page 215
40-4812072004 Harness W2 See page 217
40-4812072005 Harness W3 See page 219
40-4812018845 Harness W4 See page 224
40-4812018846 Harness W4.1 See page 225
40-4812018847 Harness W4.2 See page 226
40-4812018848 Harness W4.3 See page 227
40-4812018849 Harness W4.4 See page 228
40-4812071665 Harness W4.5 250
40-4812018853 Harness W4.8 See page 229
Swinging arm
40-4812018854 Harness W5 See page 230
40-4812018855 Harness W5.1 See page 231
40-4812018856 Harness W5.2 See page 232
40-4812018857 Harness W5.3 See page 233
40-4812018858 Harness W5.4 See page 234
40-4812071668 Harness W5.5 251
40-4812018862 Harness W5.8 See page 235
40-4812012881 Harness W6 See page 78
40-4812078518 Harness W6 252
40-4812012882 Harness W7 See page 92
40-4812078585 Harness W7 254
40-4812078666 Harness W8 255
40-4812012989 Harness W8 256
40-4812072825 Harness W15.5 See page 236
40-4812072753 Harness W15.10 257
40-4812072826 Harness W16.5 See page 237
40-4812072756 Harness W16.10 258
Mounting parts
40-4812012875 Mounting parts 260
Options
40-4812061378 End plate, el. heating, l.h. & r.h.
40-4812061378 End plate, el. heating, l.h. & r.h. 261
End plate, cpl.
40-4812061376 End plate, cpl. 262
End plate, l.h.
40-4812061373 End plate, l.h. 263
Spindle, l.h.
40-4812217905 Spindle, l.h. 267
Safety lock
40-4720003740 Safety lock 269
End plate, r.h.
40-4812061374 End plate, r.h. 270
Spindle, r.h.
40-4812061039 Spindle, r.h. 274
Safety lock
40-4720003740 Safety lock See page 269
El. heating
40-4812061382 El. heating 277
40-4812012884 Socket 230V/50HZ
40-4812012884 Socket 230V/50HZ 278
40-4812015870 Retainer hight adjustment
40-4812015870 Kit, height adjustment MOBA-MATIC 279
Retainer hight adjustment Moba
40-4720005918 Extension arm 280
40-4720007201 Swinging arm 281
Extension arm
40-4720005790 Extension arm 282
Height regulator holder, cpl.
40-4720007200 Height regulator holder, compl. 283
40-4720006020 Level
40-4720006020 Level 284
40-4812202578 Central lubrication
40-4812202578 Central lubrication 285
Central lubrication
40-4812202035 Central lubrication 287
40-4812078568 Sonic sensor, auger
40-4812078568 Sonic sensor, auger, TF 290
Retainer
40-4812228334 Retainer 291
Electric, sonic sensor
40-4812078570 Electric, sonic sensor 292
Cable, sonic sensor
40-4812078567 Cable sonic sensor 293
40-4812017942 Levelling bar
40-4812017942 Levelling bar 294
40-4812014950 Levelling
40-4812014950 Levelling 296
Available options
40-4812074772 Lighting side plate
40-4812074772 Electric, lighting side plate 298
Spot light, LED
40-4812074770 Spotlight 299
Harness
40-4812013628 Harness W9 300
40-4812061363 End plate, unheated, l.h. & r.h.
40-4812061363 End plate, unheated, l.h. & r.h. 301
End plate, cpl.
40-4812061340 End plate, cpl. 302
End plate, l.h.
40-4812061338 End plate, l.h. 303
Spindle, l.h.
40-4812217905 Spindle, l.h. See page 267
Safety lock
40-4720003740 Safety lock See page 269
Control block
End plate, r.h.
40-4812061339 End plate, r.h. 309
Spindle, r.h.
40-4812061039 Spindle, r.h. See page 274
Safety lock
40-4720003740 Safety lock See page 269
40-4812080659 Hydraulic side shield
40-4812080659 Hydraulic side shield 315
Hydraulic side shield, add ons
40-4812080770 Hydraulic side shield, add ons 316
Bulkhead plate
40-4812067459 Bulkhead plate, l.h. 318
40-4812067478 Bulkhead plate, r.h. 319
40-4812065263 Hyd. end plate, unheated, l.h. & r.h.
40-4812065263 End plate, unheated, l.h. & r.h. 320
Hydraulic, side shield
40-4812080584 Hydraulic side shield 323
Control block
40-4812078412 Control block 326
End plate
40-4812065122 End plate 327
End plate, l.h.
40-4812065010 End plate, unheated, l.h. 328
End plate, r.h.
40-4812065028 End plate, unheated, r.h. 331
Electric, side shield
40-4812078683 Electric, side shield 334
Electric, screeds
40-4812078518 Harness W6 See page 252
Electric, side shield
40-4812078585 Harness W7 See page 254
40-4812078666 Harness W8 See page 255
40-4812072753 Harness W15.10 See page 257
40-4812072756 Harness W16.10 See page 258
40-4812065266 Hyd. End plate, el. heating, l.h. & r.h.
40-4812065266 End plate, el. heating, l.h. & r.h. 337
Electric, heating
40-4812061382 El. heating See page 277
Hydraulic, side shield
40-4812080584 Hydraulic side shield See page 323
40-4812078412 Control block See page 326
End plate
40-4812065124 End plate 342
End plate, l.h.
40-4812065060 End plate, l.h. 343
End plate, r.h.
40-4812065021 End plate, r.h. 345
Electric, side shield
40-4812078683 Electric, side shield See page 334
Electric, screeds
40-4812078518 Harness W6 See page 252
Electric, side shield
40-4812078585 Harness W7 See page 254
40-4812078666 Harness W8 See page 255
40-4812072753 Harness W15.10 See page 257
40-4812072756 Harness W16.10 See page 258
40-4812217446 Conversion kit ex. operation
40-4812217446 Conversion kit ex. operation 349
Conversion kit ex. operation, l.h.
40-4812217440 Conversion kit ex. operation, l.h. 350
Conversion kit ex. operation, r.h.
40-4812217444 Conversion kit ex. operation, r.h. 351
40-4812202592 Lubrication system
40-4812202592 Lubrication system 352
Lubrication system
40-4812201941 Lubrication system 353
40-4812202565 Lubrication system
40-4812202565 Lubrication system 354
Lubrication system
40-4812202039 Lubrication system 356
Grease hose
40-4812033876 Grease hose 358
40-4812202598 Central lubrication
40-4812202598 Central lubrication 359
Central lubrication
40-4812201938 Central lubrication 360
40-4812238994 Cut off shoe
40-4812238994 Cut off shoe 361
Cut off shoe, l.h.
40-4812239018 Cut off shoe, l.h. 362
Cut off shoe, r.h.
40-4812239020 Cut off shoe, r.h. 363
40-4812075277 Retainer height adjustment Gradeline
40-4812075277 Retainer height adjustment Gradeline 364
Retainer height adjustment Gradeline
40-D275131700 Retainer height adjustment Gradeline 365
Adjusting crank
40-4720006889 Adjusting spindle 366
Positioner
40-4720007201 Swinging arm See page 281
Conversion kit BoWex coupling
40-4812076039 Conversion kit 369
40-4812078569 Sonic sensor, auger
40-4812078569 Sonic sensor, auger, MOBA 370
Retainer
40-4812228334 Retainer See page 291
Electric, sonic sensor
40-4812078571 Electric, sonic sensor 372
Cable, sonic sensor
40-4812078567 Cable sonic sensor See page 293
40-4812077115 Sonic sensor, PLC, auger
40-4812077115 Sonic sensor, PLC, auger 374
Retainer
40-4812228334 Retainer See page 291
Electric, sonic sensor
40-4812077117 Electric, sonic sensor 376
Cable, sonic sensor
40-4812078265 Cable sonic sensor 377
40-4812077116 Sonic sensor, PLC, auger
40-4812077116 Sonic sensor, PLC, auger 378
Retainer
40-4812228334 Retainer See page 291
Electric, sonic sensor
40-4812077120 Electric, sonic sensor 380
Cable, sonic sensor
40-4812078265 Cable sonic sensor See page 377
Accessories Decals (E)
40-4812018577 Decals 382
