DESCRIPTION:

Belarus 952.5 with D-245.5S3B engine Tractor Parts Catalogue & Assembly Manual 952.5-0000010 KDS – PDF DOWNLOAD

INTRODUCTION:

• The present catalogue contains the whole range of assembly units and parts for tractors
  “BELARUS-952.5“, equipped with engine D-245.5S3B.
• The catalogue is meant for organizations and firms that are concerned with tractor
  sales, operation and repair. It can be used in calculation and preparation of orders for spare
  parts and serves as a manual during tractor disassembling and assembling.
• All changes related to tractor design development are represented in respective information
  sheets.

HOW TO USE THE CATALOGUE:

• Catalogue includes tractor assembly units and parts. Assembly units and parts are divided
  into groups and subgroups according to functional attribute. This directory is well illustrated
  with axonometric figures of knocked-down tractor components.
• All parts in the figures have sequence numbers (figure numbers). For ease of catalogue reference in search for necessary part the same sequence numbers are placed in column “Pos. No.” in the text part of
  the catalogue in ascending order from top downward.
• The figures referred to in the catalogue are well-done in the terms of art and let the user get acquainted with structure and configuration of parts and assembly units. They can serve as a manual for carrying out disassembling
  and assembling operations.

For example, the following record is given in the catalogue:
«….52-2303030 2 Gear (5-7)».

It means that assembly unit “Gear” in the number of 2 pieces per unit consists of the following parts: gear (pos. 5), gasket (pos. 6) and blind plug (pos. 7). “Quantity” column gives number of assembly units and parts used in this subgroup (2303) per one tractor.

TABLE OF CONTENTS:

Belarus 952.5 with D-245.5S3B engine Tractor Parts Catalogue & Assembly Manual 952.5-0000010 KDS – PDF DOWNLOAD

Introduction 4
How to use this catalogue 4
Application 5
Index of groups and subgroups of catalogue assembly units and parts 8
Assembly units and parts 12

Description Page
10 Diesel engine mechanisms
1001 10.1 Engine assembly 12
Fuel feed system
1101 11.1 Fuel tank 14
1108 11.2 Fuel feed control 16
1109 11.3 Air cleaner assembly 18
11
1117 11.4 Fuel filter assembly 20
Exhaust system
1201 12.1 SCR-system tank assy (1220.5-1201010) 22
1201 12.2 SCR-system tank assy (1220.5R-1201010/-А) 24
1204 12.3 Feed system (1220.5-1204010) 26
1204 12.4 Feed system (1220.5R-1204010) 28
1205 12.5 Muffler assembly (1220.5-1205005) 30
1205 12.6 Muffler assembly (1220.5R-1205005/-А) 32
1209 12.7 Tank heating system (1220.5-1209010) 34
12
1209 12.8 Tank heating system (1220.5R-1209010) 36
Cooling system
1301 13.1 Cooling unit 38
1309 13.2 Fan guard 40
13
1317 13.3 Cooler assembly 42
Clutch
1601 16.1 Clutch assembly 240-1005009-03 44
1601 16.1а Clutch assembly 240-1005009-06 46
1601 16.2 Clutch housing 48
1601 16.3 Clutch housing. Release yoke 52
1601 16.4 Clutch housing
(PTO drive, Pump drive of hitch hydraulic system)
54
1601 16.5 Clutch housing. PTO drive. (neng=1800 rpm) 56
16
1602 16.6 Clutch control 58
Gearbox
1721 17.1 Mechanical reducing gear unit/
mechanical speed-increase unit
60
1721 17.2 Synchronized reducing gear unit/
synchronized speed-increase unit
62
1723 17.3 Control of mechanical*/synchronized** reducing gear unit or
speed-increase unit
64
1721 17.4 Synchronized reverse gear unit 66
1723 17.5 Control of synchronized reverse gear unit 68
Gearbox. GB configuration variants of the tractor
BELARUS-952.5
70
1701 17.6 GB casing. FDA drive 72
1701 17.7 Primary and secondary shaft of mechanical GB 74
1701 17.8 Primary and secondary shaft of synchronized GB 76
1701 17.9 First gear and reverse shaft 78
1701 17.10 Intermediate shaft. Inner shaft 80
1701 17.11 Shift forks housing of mechanical GB 82
1701 17.12 Shift forks housing of synchronized GB 84
1703 17.13 Mechanism of right single-lever GB control 86
1703 17.14 Double-lever control of synchronized GB 90
1742 17.15 Mechanical creeper 94
17
1742 17.16 Hydraulic creeper 98
– 9 –
