FILE FORMAT:
LANGUAGE:ENGLISH
PAGES:86
DOWNLOADABLE:YES
FILE TYPE:PDF
DESCRIPTION:
Bobcat 371 Skid Steer Loader Service Repair Workshop Manual – Download ( Gasoline L P Gas )
This manual is written in two parts: To provide instruction for proper routine servicing and adjustments of the Bobcat such as the 50 hour check and regularly scheduled periodic inspections established by the Service Schedule, and to provide detailed overhaul instructions of the power train, loader hydraulic system and general machine main frame components. Refer to the Owners Manual for general operating instructions (Starting Procedure, Daily Checks, Bucket Operation, Minor Maintenance, etc).
INSPECTION:
A general inspection of the following items should be made whenever the machine has been
serviced of repaired:
1. Check hydraulic fluid level, engine oil level and fuel supply.
2. Check for any sign of fuel, oil or hydraulic fluid leaks.
3. Lubricate the machine.
4. Check battery condition, electrolyte level and cables.
5. Check air cleaner for damage or leaks. Check element and replace if necessary.
6. Check transmission drive belt and hydraulic drive belt for wear and tension.
7. Check tires for wear and pressure.
8. Check Bob–Tach wedges for condition.
9. Check safety items for condition. (Operator Protective Guard, Seat Belt, Safety Treads on
steps, Boom Stop).
10. Make a visual inspection for loose or broken parts or connections.
Advise the owner if any of the above items require service or repair
TABLE OF CONTENTS:
Wheel Hub Bolts 60
Wheel Lug Bolts 45–50
Wheel Sprocket Retaining Cap Bolts (Lubricated)45
Outside Clutch Chain Idler Sprocket 60
5/8” Clutch Pin Lock Nut 60
Lower Jackshaft Assembly Shaft Nut 60
Inside Chain Idler Sprocket Bolts 40
Steering Lever Bushing Nuts 130
Upper Jackshaft 1–1/8” Nut (Early Model Machines) 120
Upper Jackshaft Cap Screw (Late Model Machines) 60
Upper Jackshaft Sheave (Pulley) Bolt 60
Final Drive Chain Idler Sprocket Bolts(5/8” bolt) 120
(1/2” bolt) 80
Pivot & Cylinder Rod Bolts160
Crankshaft Sheave Bolt (On Engine) 60
Hydraulic Pump Sheave Bolt35
Transmission Case Cover Bolts 12–15
Control Valve Tie Rod Nuts (HUSCO)(5/16”) 14
(3/8”) 33
Control Valve Tie Rod Nuts (WARD) 16
Pump Assembly Screws 25
Engine Cylinder Head Bolts25 – 30 ft–lbs (34 – 40,7 Nm)
Spark Plugs20 ft–lbs (27 Nm)
