FILE DETAILS:

Bomag BPR 70 70 D Reversible Vibrating Plate Operating instructions Manual 00806761 – PDF DOWNLOAD

Language : English
Pages : 76
Downloadable : Yes
File Type : PDF
Size: 1.62 MB

DESCRIPTION:

Bomag BPR 70 70 D Reversible Vibrating Plate Operating instructions Manual 00806761 – PDF DOWNLOAD

Foreword

BOMAG manufactures machines for earth, asphalt, and refuse compaction, as well as stabilizers/recyclers, milling machines, and finishers. BOMAG’s vast experience, combined with state-of-the-art production and testing methods such as lifetime tests of all vital components and highest quality demands, ensures maximum reliability of your machine.

This manual includes:

• Safety regulations
• Operating instructions
• Maintenance instructions
• Troubleshooting

Using these instructions will:

• Help you become familiar with the machine.
• Prevent malfunctions caused by unprofessional operation.

Compliance with the maintenance instructions will:

• Enhance the reliability of the machine on construction sites.
• Prolong the lifetime of the machine.
• Reduce repair costs and downtimes.

BOMAG will not assume liability for the function of the machine:

• If it is handled in a way not complying with the usual modes of use.
• If it is used for purposes other than those mentioned in these instructions.

No warranty claims can be lodged in case of damage resulting from:

• Operating errors
• Insufficient maintenance
• wrong fuels and lubricants.

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

Bomag BPR 70 70 D Reversible Vibrating Plate Operating instructions Manual 00806761 – PDF DOWNLOAD

1 Foreword 3
2 Technical Data 7
3 Safety regulations 11
4 Indicators and Controls 19
4.1 General notes 20
4.2 Description of indicators and control elements 20
4.3 Function of the Economizer 22
5 Operation 25
5.1 General 26
5.2 Tests before taking into operation 26
5.3 Folding down the steering rod 27
5.4 Operating the low oil level safety device 27
5.5 Starting the engine 28
5.6 Emergency starting with safety crank handle 29
5.7 Operation of Economizer 31
5.8 Work/operation 33
5.9 Backup protection 34
5.10 Stopping the vibratory plate, shutting down the engine 35
5.11 Loading/transport 36
6 Maintenance 37
6.1 General notes on maintenance 38
6.2 Fuels and lubricants 39
6.3 Table of fuels and lubricants 41
6.4 Running-in instructions 42
6.5 Maintenance table 43
Maintenance every day 45
6.6 Clean the machine 45
6.7 Check the engine oil level 45
6.8 Check the fuel level 46
6.9 Check the hydraulic oil level 47
6.10 Check the air filter service indicator 47
Maintenance every month 49
6.11 Clean the cooling fins and the cooling air intake openings 49
6.12 Drain the sludge from the fuel tank 50
Maintenance every 6 months 51
6.13 Check the battery condition, grease the poles 51
6.14 Check, adjust the valve clearance 52
Table of Contents
6 BOMAG BPR 70/70 D
6.15 Check the oil level in the exciter housing 53
Maintenance every year 55
6.16 Change engine oil and oil filter 55
6.17 Replacing the fuel filter 56
6.18 Changing the oil in the exciter housing 57
6.19 Check the rubber buffers 58
6.20 Check the V-belt tension, if necessary replace the V-belt 59
Maintenance every 2 years 61
6.21 Change hydraulic oil and filter 61
As required 63
6.22 Check, clean the air filter, replace if necessary 63
6.23 Tightening the screws 64
6.24 Engine conservation 65
7 Trouble shooting 67
7.1 General notes 68
7.2 Starting with jump wires 68
7.3 Engine problems 70
7.4 Trouble shooting Economizer 72
8 Disposal 73
8.1 Final shut-down of machine 74
