Cat Bucyrus SCOPE OF WORK RH170 Terex Mining Hydraulic Shovel Technical Manual BI638293 – PDF DOWNLOAD

1. MACHINE SET UP
1.1 Machine to be set up on a clean flat level surface.
1.2 Working Equipment positioned at 90 degrees to the Track Frames so the Stick is in the vertical position and the Bucket is grounded.
1.3 Area around Boom Cylinder should be washed down.

2. ISOLATION PROCEDURE

2.1 Relevant Site Isolation Procedures must be followed. An “Out of Service” and
“Personal Danger” tag must be fitted to key switch in the Cab.
Note: Machine must not be completely isolated at the start of the job because the
machine must be run to enable the Boom Cylinder to be removed.

3.SERVICES REQUIRED

3.1 Crane or lifting device capable of lifting 5000kg.
3.2 Pressure Cleaner.
3.3 Work platform capable of carrying two people and tools.

4. PERSONNEL REQUIRED

4.1 2 X Mechanical Tradespeople.
4.2 1 X Machine Operator.
4.3 1 X Crane Operator (Ticketed).

5. PARTS REQUIRED

1 X Boom Cylinder PIN 2455006X (4720kg)
2 X Bush Superstructure PIN 2455027
1 X Pin Superstructure PIN 2417802
1 X Pin Boom PIN 2417802
2 X Bush Boom PIN 2455027
2 X Seal Ring PIN 1725421
1 X Assembly Paste A080095

6. SAFETY
6.1 Personnel must at all times wear the correct safety equipment issued to them, as
required by their location, i.e. helmet, gloves, glasses, personal harness etc
