Cessna 414 & 414A Aircraft Shop Manual 1970-1985

File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader & WinZip

IMAGE PREVIEW:

INSPECTION INSTRUCTIONS
A. Remove avionic equipment, oxygen bottles and other equipment per the Service Manual to gain full
access to wheel well structure.
B. Visually inspect wheel well structure including webs, stiffeners, braces, brackets and support channels
for cracks, loose rivets, corrosion and deterioration.
C. Inspect local areas surrounding the nose gear attach points and drag brace attach points for cracks,
loose rivets corrosion and deterioration.
D. Reinstall all equipment removed from nose area for access.

REPAIR/MODIFICATION
Repair using standard repair procedures in accordance with the Cessna Service Manual and approved
data if primary in scope, or replace weakened parts. However, care must be taken not to over-stiffen
the web areas. Some flexibility is required to ensure that the gear can travel to over-center position
during extension and retraction without overloading the structure.
