Gehl 600 Series Finger Wheel V-Rakes Parts Manual(909922C) – PDF DOWNLOAD

Gehl 600 Series Finger Wheel V-Rakes Parts Manual(909922C) – PDF DOWNLOAD

FILE DETAILS:

Gehl 600 Series Finger Wheel V-Rakes Parts Manual(909922C) – PDF DOWNLOAD

Language : English
Pages : 48
Downloadable : Yes
File Type : PDF
Size: 2.61 MB

TABLE OF CONTENTS:

Gehl 600 Series Finger Wheel V-Rakes Parts Manual(909922C) – PDF DOWNLOAD

Introduction Inside Front Cover
Table of Contents 1
Decal Locations 2-3
Attachment Frame 4-7
Drawbar 8-9
Windrow Width Adjustment Device 10-11
Frames 12-13
Adjustment Arm 14-15
Hydraulics 16-19
Front Caster Wheel 20-21
Finger Wheels (Right & Left) 22-23
2-Wheel Extension Kit 24-25
4-Wheel Extension Kit 26-27
Flex Frame Kit 28-29
5th & 6th Ground Wheels 30-31
Transport Safety Bars 32
Options & Accessories 33-39
Hitchjack, Wind Shield Kit 33
Splitter Wheel Kit 34-37
Safety Chain, Transport Light Kit 38
Tandem Axle 39
Alphabetical Index 40
Numerical Index 41-43
Hydraulic Fitting Data 44
Standard Hardware Torque Specifications Inside Back Cover

DESCRIPTION:

Gehl 600 Series Finger Wheel V-Rakes Parts Manual(909922C) – PDF DOWNLOAD

Introduction

• When ordering service parts, specify the correct part number, full description, quantity required, the unit model number and serial number. The model number and serial number for the Wheel Rake is on a decal located on the back side of the left side width adjustment wheel pivot frame member.
• “Right’’ and “left’’ are determined from a position standing at the rear of the unit facing the direction of travel. GEHL Company reserves the right to make changes or improvements in the design or construction of any part of the unit without incurring the obligation to install such changes on any previously delivered units.

GENERAL INFORMATION

• Decal location information is provided to assist in the proper selection and application of new decals, in the event the original decals become damaged or the machine is repainted. Refer to the listing for the illustration reference number, part number, description and quantity of each decal provided in the kit. Refer to the appropriate illustrations for replacement locations.
• To ensure proper selection of replacement decals, compare the close-up photographs to your machine BEFORE starting to refinish the unit. Then, circle each pictured decal applicable to your machine while checking off its part number in the listing. After you have verified all of the decals needed for replacement, set aside unneeded decals for disposal.
