Gehl CTL65 Parts Manual 917294 – PDF DOWNLOAD

Gehl CTL65 Parts Manual 917294 – PDF DOWNLOAD

FILE DETAILS:

Gehl CTL65 Parts Manual 917294 – PDF DOWNLOAD

Language : English
Pages : 246
Downloadable : Yes
File Type : PDF
Size: 24.9 MB

IMAGES PREVIEW OF THE MANUAL:

DESCRIPTION:

Gehl CTL65 Parts Manual 917294 – PDF DOWNLOAD

Introduction:

For your safety and continued proper operation, use only genuine GEHL® service parts. When ordering service parts, specify the correct part number, full description, quantity required, the unit model number and serial number. The model and serial number decal for this unit is located on the right rear riser.

• “Right” and “Left” are determined from a position sitting on the seat and facing forward. Manitou Americas, Inc. reserves the right to make changes or improvements in the design or construction of any part of the unit without incurring the obligation to install such changes on any previously delivered units.
• Refer to the abbreviations table located on this page for the various fastener descriptions. Standard attaching hardware torque values are also provided on the inside back cover. Items shown in the parts list that do not have part numbers are shown for reference purposes only and are NOT available for purchase.

TABLE OF CONTENTS:

Gehl CTL65 Parts Manual 917294 – PDF DOWNLOAD

INTRODUCTION
INTRODUCTION 1
SECTION A: MAIN LOADER COMPONENT
TRACK ROLLER A 2
TRACK ROLLER B 4
FRONT IDLER 6
TRACK ADJUSTER 8
TRAVEL DEVICE 10
CRAWLER BELT 12
MAINFRAME 14
LIFT ARM STOP 16
LIFT ARM STOP (WITH HOOK ASSEMBLY) 18
OPERATION LEVER AND STAND 20
PIPING; OPERATION LEVER 22
ENGINE AND ACCESSORIES (1/4) 24
ENGINE AND ACCESSORIES (2/4) 26
ENGINE AND ACCESSORIES (3/4) 29
ENGINE AND ACCESSORIES (4/4) 31
DRAIN PLUG 33
CONTROL BOX – RIGHT 35
CONTROL BOX – LEFT 37
ENGINE CONTROL 39
ELECTRICAL (1/2) SN 223000001 – 223000296 41
ELECTRICAL (2/2) SN 223000001 – 223000296 44
ELECTRICAL (1/3) SN 223000297 – 223000854 47
ELECTRICAL (2/3) SN 223000297 – 223000854 50
ELECTRICAL (3/3) SN 223000297 – 223000854 52
ELECTRICAL (1/3) SN 223000855 and Up 54
ELECTRICAL (2/3) SN 223000855 and Up 56
ELECTRICAL (3/3) SN 223000855 and Up 58
ELECTRICAL (Multi-Functional Grip) 60
ELECTRICAL – CAB 62
BATTERY 64
REAR LAMP 66
MAINTENANCE LIGHT SOCKET 68
CONTROL VALVE AND ACCESSORIES (1/2) 70
CONTROL VALVE AND ACCESSORIES (2/2) 73
PIPING; HYDRAULIC TANK (1/2) 76
PIPING; DRIVE MOTORS (2/2) 78
PUMP DRIVE 80
HYDRAULIC TANK 82
FUEL TANK AND PIPING SN 223000001 – 223000833 84
FUEL TANK AND PIPING SN 223000834 and Up 87
COVERS 91
REAR GRILLE 94
ENGINE COVER 96
FLOOR FRAME 98
SEAT 100
SEAT COMPONENTS 102
SEAT SWITCH SN 223000001 – 223000182 104
SEAT SWITCH SN 223000183 and Up 106
RESTRAINT BAR 108
ROPS 110
ROPS 112
ROPS LIGHTS AND HARNESS 114
REAR MIRROR 116
REARVIEW MIRROR 118
MANUAL BOX 120
LIFT ARM 122
ATTACHMENT SYSTEM 125
PIPING; LIFT ARM 127
AUXILIARY HYDRAULICS 129
FOOT THROTTLE 131
DECALS
DECALS – GENERAL INFORMATION 134
DECALS (1 of 6) 135
DECALS (2 of 6) 138
DECALS (3 of 6) 141
DECALS (4 of 6) 144
DECALS (5 of 6) 147
DECALS (6 of 6) 150
SECTION B: HYDRAULIC COMPONENTS
CONTROL VALVE 153
PILOT VALVE (LEFT HAND) (MULTI-FUNCTIONAL GRIP) 156
PILOT VALVE (RIGHT HAND) (MULTI-FUNCTIONAL GRIP) 158
HANDLE (MULTI-FUNCTIONAL GRIP WITH SLIDE SWITCH) 160
HANDLE (MULTI-FUNCTIONAL GRIP WITH FIVE SWITCHES) 162
SUB VALVE 164
SOLENOID VALVE; 1 BLOCK 166
ELECTRICAL PROPORTION VALVE 168
LIFT CYLINDER 170
TILT CYLINDER 172
TRAVEL MOTOR (1/3) 174
TRAVEL MOTOR (2/3) 176
TRAVEL MOTOR (3/3) 178
HYDRAULIC PUMP (1/4) 180
HYDRAULIC PUMP (2/4) 182
HYDRAULIC PUMP (3/4) 184
HYDRAULIC PUMP (4/4) 186
GEAR PUMP 188
SECTION C: FILTER LISTING, KITS AND ACCESSORIES
CTL65 FILTER PART NUMBERS 190
Analysis Kits – Contact your Gehl Dealer 191
Additional Accessories 192
KITS AND ACCESSORIES 810946 Universal Radio Kit 193
KITS AND ACCESSORIES 810831 Door Kit – Glass Door SN T9702A01633 and Up 195
KITS AND ACCESSORIES 810831 Door Kit Glass Door SN T9702A01632 and Before 198
KITS AND ACCESSORIES Auxiliary Couplers Service Kits 201
KITS AND ACCESSORIES 810901 Side Window Kit 203
KITS AND ACCESSORIES 810898 Impact-Resistant Door Kit 205
KITS AND ACCESSORIES 811343 Pre-Cleaner Kit 208
KITS AND ACCESSORIES 811350 Power-A-Tach Kit 210
KITS AND ACCESSORIES 811350 Power-A-Tach Kit 213
KITS AND ACCESSORIES 811347 HVAC Kit 216
KITS AND ACCESSORIES 811347 HVAC Kit 219
KITS AND ACCESSORIES 811347 HVAC Kit 222
KITS AND ACCESSORIES 811347 HVAC Kit Service Parts 193930 224
KITS AND ACCESSORIES 811347 HVAC Kit 195910 Drawing (Reference) Service Parts 227
KITS AND ACCESSORIES 244689 Service Parts 229
KITS AND ACCESSORIES 811347 HVAC Kit Schematic 231
KITS AND ACCESSORIES 811428 14-Pin Connector Kit 232
KITS AND ACCESSORIES 811604 Counterweight Kit 234
KITS AND ACCESSORIES 805855 Block Heater Kit 236
SECTION D: SPECIFICATIONS AND TABLES
Torque Specifications 238
O-Ring Table, Coupling & Adapter Torque Table 239
