Gehl Scavenger Manure Spreaders MS1309, MS1312, MS1315, MS1322 Operators Manual 907170C – PDF DOWNLOAD

DESCRIPTION:

Gehl Scavenger Manure Spreaders MS1309, MS1312, MS1315, MS1322 Operators Manual 907170C – PDF DOWNLOAD

CHAPTER 1
INTRODUCTION

• Your decision to purchase this piece of Gehl equipment was a good one. We are sure that your decision was carefully considered and that you are looking forward to many years of work from this machine. Gehl Company has invested much time and effort in developing its lines of equipment.
• The equipment you have purchased is built with a great deal of pride and designed to give you long life, efficient operation, durability and dependability. This manual was developed specifically for the machine you have purchased. The information within is for your assistance in preparing, adjusting, maintaining and servicing your machine.
• More importantly, this manual provides an operating plan for safe and proper use of your machine. Major points of safe operation are detailed in the SAFETY chapter of this manual. Refer to the Table of Contents for an outline (by chapters) of this manual.
• Use the Index, located at the back of this manual, for specific chapter and topic/page number references. Modern machinery has become more sophisticated and, with that in mind, Gehl Company asks that you read and understand the contents of this manual COMPLETELY and become familiar with your new machine, BEFORE attempting to operate it. A plastic pouch is provided on the unit for storing the operator’s manual.
• After using the manual, please return it to the pouch and keep it with the unit at all times. Furthermore, if this machine is resold, Gehl Company recommends that this manual be given to the new owner. If this machine was purchased “used,” or if the owner’s address has changed, please provide your Gehl dealer or Gehl Company service department with the owner’s name and current address, along with the machine model and serial number.
• This will allow the registered owner information to be updated, so that the owner can be notified directly in case of an important product issue, such as a safety update program. The Gehl dealer organization stands ready to provide you with any assistance you may require and carries genuine Gehl service parts.
• All parts should be obtained from or ordered through your Gehl dealer. Give complete information about the part and include the model and serial numbers of your machine. Record the serial number in the space provided on the pictorial, as a handy record for quick reference. Typical model & serial number plate 13  COMPANY W E S T B E N D , W I 5 3 0 9 5 U S A M O D E L N O . S E R I A L N O . (Fill In) (Fill In) Model and serial numbers for this unit are on a decal located on the left front side of the Spreader tank.
• “Right” and “left” are determined from a position standing behind the Spreader. From this position, the expeller is on the “right” side. Gehl Company reserves the right to make changes or improvements in the design or construction of any part without incurring the obligation to install such changes on any unit previously delivered. Standard hardware torques appear in a chart at the end of the manual.
• Throughout this manual information is provided that is set in italic type and introduced by the word NOTE or IMPORTANT. BE SURE to read carefully and comply with the message or directive given. Following this information will improve your operating and maintenance efficiency, help you to avoid costly breakdowns and unnecessary damage, and extend your machine’s life.

TABLE OF CONTENTS:

Gehl Scavenger Manure Spreaders MS1309, MS1312, MS1315, MS1322 Operators Manual 907170C – PDF DOWNLOAD

Warranty Inside Front Cover
Chapter 1
Introduction 2
Chapter 2
Specifications 3-4
Chapter 3
Checklists 5-7
Chapter 4
Safety 8-14
Chapter 5
Controls & Safety Equipment 15-17
Chapter 6
Operation 18-27
Chapter 7
Care & Maintenance 28-33
Adjustments 28-29
Lubrication 30-31
Service 28-33
Chapter 8
Preparing for Field Operation 34
Chapter 9
Transporting 35-36
Chapter 10
Storage 37
Chapter 11
Troubleshooting 38-39
Chapter 12
Set-up & Assembly 40-46
Chapter 13
Optional Features & Accessories 47
Chapter 14
Decal Locations 48-49
Chapter 15
Maintenance Log 50
Index 51
Hydraulic Fitting Data 52
Standard Hardware
Torque Data Inside Back Cover

IMAGES PREVIEW OF THE MANUAL:
