Gehl Z45 Excavator (SN 00700 and Before) Parts Manual 50940085 – PDF DOWNLOAD

Gehl Z45 Excavator (SN 00700 and Before) Parts Manual 50940085 – PDF DOWNLOAD

FILE DETAILS:

Gehl Z45 Excavator (SN 00700 and Before) Parts Manual 50940085 – PDF DOWNLOAD

Language : English
Pages : 264
Downloadable : Yes
File Type : PDF
Size: 125 MB

TABLE OF CONTENTS:

Gehl Z45 Excavator (SN 00700 and Before) Parts Manual 50940085 – PDF DOWNLOAD

INTRODUCTION 1
SPECIAL TOOLS, PAINT 4
FIGURE INDEX (1) – MAIN PARTS 6
FIGURE INDEX (2) – HYDRAULIC SECTION 9
FIG. 1 – LABEL (CANOPY) 12
FIG. 2 – LABEL (CABIN) 15
FIG. 5 – SAFETY LABEL (CANOPY) 18
FIG. 6 – SAFETY LABEL (CABIN) 20
FIG. 7 – SILENCER & AIR CLEANER 22
FIG. 8 – ACCELERATOR 24
FIG. 9 – ENGINE MOUNT 26
FIG. 10 – RADIATOR & MOUNT 28
FIG. 11 – FUEL TANK 31
FIG. 12 – FUEL LINE 33
FIG. 13 – BATTERY 35
FIG. 14 – ELECTRIC PART (AROUND ENGINE) 37
FIG. 15 – ELECTRIC PART (AROUND FRAME) 39
FIG. 16 – ELECTRIC PART (EQUIPMENT) 41
FIG. 17 – ELECTRIC PART (STARTING SWITCH) 43
FIG. 18 – ELECTRIC PART (QUICK COUPLER : SWITCH BOX) 45
FIG. 19 – ELECTRIC PART (WORK LAMP) 47
FIG. 21 – TRAVEL ALARM 49
FIG. 22 – WINDOW WASHER 51
FIG. 23 – HEATER 53
FIG. 24 – AIR CONDITIONER (ELECTRIC PART) 55
FIG. 25 – AIR CONDITIONER (HEATER HOSE) 57
FIG. 26 – AIR CONDITIONER (ENGINE RELATED) 59
FIG. 27 – AIR CONDITIONER (CABIN RELATED) 61
FIG. 28 – AIR CONDITIONER (CONDENSER RELATED) 63
FIG. 29 – AIR CONDITIONER (PIPING) 65
FIG. 30 – SPROCKET 67
FIG. 31 – IDLER & ADJUST 69
FIG. 32 – TRACK ROLLER 71
FIG. 33 – CARRIER ROLLER 73
FIG. 34 – CRAWLER 75
FIG. 35 – VALVE PLATE 77
FIG. 36 – CONTROL EQUIPMENT (TRAVEL LEVER) 79
FIG. 37 – CONTROL EQUIPMENT (SWING PEDAL) 81
FIG. 38 – CONTROL EQUIPMENT (LOW-HIGH PEDAL) 83
FIG. 39 – CONTROL EQUIPMENT (LOCK LEVER & STAND : LEFT) 85
FIG. 40 – CONTROL EQUIPMENT (LOCK LEVER & STAND : RIGHT) 87
FIG. 41 – CONTROL EQUIPMENT (BLADE LEVER) 89
FIG. 42 – CONTROL EQUIPMENT (P.T.O.) 91
FIG. 43 – ARM REST 93
FIG. 44 – TRAVEL FRAME 95
FIG. 45 – TURNING FRAME 97
FIG. 46 – GREASING 99
FIG. 47 – TURNING BEARING 101
FIG. 48 – FRAME GUARD 103
FIG. 50 – COVER (TURNING FRAME) 105
FIG. 51 – COVER (TRAVEL FRAME) 107
FIG. 52 – COVER (BONNET) 109
FIG. 53 – STEP (1) 111
FIG. 54 – STEP (2) 113
FIG. 55 – INSTRUMENT PANEL 115
SEAT 117
FIG. 56 – SEAT MOUNT 119
FIG. 57 – SEAT MOUNT COVER & HAND HOLD 122
FIG. 58 – SEAT PLATE 124
FIG. 59 – BONNET (REAR) 126
FIG. 61 – BONNET (FRONT) 128
FIG. 62 – BONNET (LEFT) 130
FIG. 64 – BONNET (RIGHT) 132
FIG. 66 – CANOPY 134
FIG. 68 – CABIN (BODY) 136
FIG. 69 – CABIN (GLASS) 138
FIG. 70 – CABIN (ACCESSORY) 141
FIG. 71 – CABIN (ELECTRIC PART) 143
FIG. 72 – CABIN DOOR (FRONT) 145
FIG. 73 – CABIN DOOR (REAR) 147
FIG. 74 – CABIN (COVER) 149
FIG. 75 – CABIN (FITTING) 151
FIG. 76 – REARVIEW MIRROR 153
FIG. 77 – HYD. OIL PUMP & JOINT 155
FIG. 78 – BOOM CYLINDER 158
FIG. 79 – ARM CYLINDER 161
FIG. 80 – BUCKET CYLINDER 164
FIG. 81 – SWING CYLINDER 166
FIG. 82 – BLADE CYLINDER 168
FIG. 83 – HITCH CYLINDER (QUICK COUPLER) 170
FIG. 84 – TRAVEL MOTOR 172
FIG. 85 – TURNING MOTOR 175
FIG. 86 – SWIVEL JOINT 178
FIG. 87 – CONTROL VALVE (1/7) 180
FIG. 88 – CONTROL VALVE (2/7) 183
FIG. 89 – CONTROL VALVE (3/7) 186
FIG. 90 – CONTROL VALVE (4/7) 188
FIG. 91 – CONTROL VALVE (5/7) 190
FIG. 92 – CONTROL VALVE (6/7) 192
FIG. 93 – CONTROL VALVE (7/7) 194
FIG. 94 – 2-WAY VALVE 196
FIG. 95 – REMOTE CONTROL VALVE 198
FIG. 96 – HYD. OIL TANK 200
FIG. 97 – HYD. OIL PIPING (FITTING : PUMP) 202
FIG. 98 – HYD. OIL PIPING (FITTING : TURNING MOTOR) 204
FIG. 99 – HYD. OIL PIPING (FITTING : CONTROL VALVE) 206
FIG. 100 – HYD. OIL PIPING (TANK-PUMP-CONTROL VALVE) 208
FIG. 101 – HYD. OIL PIPING (VALVE-TURNING MOTOR) 210
FIG. 102 – HYD. OIL PIPING (VALVE-SWIVEL-SWING CYLINDER) 212
FIG. 103 – HYD. OIL PIPING (RETURN) 214
FIG. 104 – HYD. OIL PIPING (P.T.O. : TURNING FRAME) 216
FIG. 105 – HYD. OIL PIPING (CONTROL VALVE-FRAME END) 219
FIG. 106 – HYD. OIL PIPING (TRUCK FRAME) 221
FIG. 107 – HYD. OIL PIPING (BOOM) 223
FIG. 108 – HYD. OIL PIPING (P.T.O. : BOOM-ARM) 225
FIG. 110 – HYD. OIL PIPING (QUICK COUPLER) 227
FIG. 112 – CONTROL PIPING (PUMP-VALVE-RETURN) 229
FIG. 113 – CONTROL PIPING (2-WAY VALVE : 1) 231
FIG. 114 – CONTROL PIPING (2-WAY VALVE : 2) 233
FIG. 115 – CONTROL PIPING (VALVE-BLADE VALVE) 235
FIG. 116 – CONTROL PIPING (2-WAY VALVE : FITTING) 237
FIG. 117 – ACCUMULATOR 239
FIG. 118 – BOOM BRACKET 241
FIG. 120 – BOOM 243
FIG. 122 – ARM 246
FIG. 124 – BUCKET ARM & LINK 248
FIG. 126 – QUICK COUPLER 250
FIG. 128 – BLADE 252
HYDRAULIC QUICK-CONNECT COUPLERS 254
TORQUE SPECIFICATIONS 256

DESCRIPTION:

Gehl Z45 Excavator (SN 00700 and Before) Parts Manual 50940085 – PDF DOWNLOAD

General:

•MANITOU AMERICAS, INC. reserves the right to make changes or improvements in the design or construction of any part of the machine without incurring the obligation to install such changes on any previously delivered machines.• This parts manual should not be used as a technical data reference; it uses simplified illustrations and does not detail servicing procedures.

Parts Ordering Information:

• When ordering service parts, specify the correct part number, full description and quantity required, as well as the machine and engine model and serial numbers. For your safety and continued proper operation, use only genuine GEHL service parts.• “Right”, “left”, “front” and “back” are determined from a position sitting on the operator’s seat and facing forward, and the excavator “house” rotated so that the blade is also facing forward.

Torque Charts:

Standard attaching hardware torque values are provided on the inside back cover, and some torque values may be shown in illustrations. Metric torque values are shown in Newton-meters, and are converted to foot-pounds by multiplying by 0.738.

Illustrations and Parts Lists:

• Not all parts shown in the illustrations may be included in the parts listings; some are not serviced separately or are not included on engines sold in all areas.• Ref. Nos. shown in the parts listings without part numbers are shown for reference purposes only and are not available for purchase.• Boxes or brackets may be used in some illustrations to indicate assemblies (part groupings), or in some cases to highlight different versions of individual parts or assemblies.• Text references may be present on some illustrations to provide additional information.• Some illustrations will contain circled letters or a circled combination of letters and numbers in addition to the regular number callouts. These special callouts may be used to identify hydraulic port locations which are marked on components, or to identify the two ends of a hose, tube, or other part that is shown split in the illustration. They may also be used to indicate a common reference point when different versions of components are shown on the illustration.
