Haulotte 6543A Operator’s Manual 4001118650 – PDF DOWNLOAD

Haulotte 6543A Operator’s Manual 4001118650 – PDF DOWNLOAD

FILE DETAILS:

Haulotte 6543A Operator’s Manual 4001118650 – PDF DOWNLOAD

Language : English
Pages :104
Downloadable : Yes
File Type : PDF

TABLE OF CONTENTS:

Haulotte 6543A Operator’s Manual 4001118650 – PDF DOWNLOAD

FOREWORD
1 – User responsibility 8
11 – Owner’s responsibility 8
12 – Employer’s responsibility 8
13 – Trainer’s responsibility 8
14 – Operator’s responsibility 9
2 – Safety 10
21 – Safety instructions 10
211 – Incorrect use 10
212 – Falling Hazards 10
213 – Overturning / Tip-over Hazards 12
214 – Risk of electric shock (electrocution) 14
215 – Explosion / Fire Hazards 15
216 – Crushing / Collision Hazards 15
217 – Risk of involuntary movements 16
3 – Safety inquiries 17
4 – Incident notification 17
5 – Compliance 18
51 – Product modification 18
511 – Implementing manufacturer safety campaigns 18
52 – Product specifications 18
53 – Change of Ownership Notification 18
FAMILIARIZATION
1 – General safety 19
11 – Intended use 19
12 – Decal content 20
13 – Symbols and colors 21
14 – Level of severity 21
15 – Symbols legend and definitions 22
2 – Models description 23
3 – Primary machine components 24
31 – Layout 24
32 – Ground control box 26
321 – Layout 26
33 – Platform control box 30
331 – Layout 30
4 – Performance Specifications 32
41 – Technical characteristics 32
42 – Working area / Range of motion 34
5 – Decals and markings locations 36
4
Operator’s manual
C
PRE-OPERATION INSPECTION
1 – Recommendations 49
2 – Working area assessment 49
3 – Inspection and Functional test 50
31 – Daily inspection 50
32 – Inspection Form 54
4 – Safety functional checks 56
41 – E-Stop button check 56
42 – Activation of controls 57
43 – Fault detector 57
431 – Indicators/LED’s test 57
44 – Automatic engine cut-out 57
45 – Outriggers 58
D
OPERATION INSTRUCTIONS
1 – Operation 59
11 – Introduction 59
12 – Operation from the ground control box 61
13 – Operation from the platform control box 62
2 – Ground control box 63
21 – Boom and arm controls 63
3 – Platform control box 65
31 – To start and stop the machine 65
32 – Platform box controls (Primary station) 65
33 – Additional controls 66
4 – Outriggers extension 67
5 – Rescue and emergency procedures 70
51 – In case of power loss 70
511 – Manual Boom Operation 70
5111 – Manual retraction 71
5112 – Manual rotation 71
5113 – Manual Boom Lowering Procedure 72
52 – To rescue operator in platform 73
53 – No power available 73
6 – Transportation 74
61 – Putting in transport position 74
611 – Machine layout 74
612 – Transporting on to a truck bed 75
613 – Unloading 75
62 – Towing 76
621 – Procedure to hitch and tow 77
63 – Storage 78
64 – Lifting operation 80
7 – Cold Weather Recommendations 81
71 – Engine oil 81
72 – Hydraulic oil 81
5
CONTENTS
Operator’s manual
E
GENERAL SPECIFICATIONS
1 – Machine dimensions 83
2 – Major component masses 84
3 – Acoustics and vibrations 84
4 – Wheel/Tire assembly 84
41 – Technical specifications 84
42 – Inspection and maintenance 85
5 – Options 88
51 – Important 88
52 – Platform rotator 88
F
MAINTENANCE
1 – General 89
2 – Maintenance Schedule 90
3 – Inspection program 90
31 – General program 90
32 – Daily inspection 91
33 – Periodic inspection 91
34 – Reinforced inspection 91
35 – Major inspection 92
4 – Repairs and adjustments 93
