Hyundai R480LC-9MH Hydraulic Excavator Operator's Manual 2023 - PDF

Hyundai R480LC-9MH Hydraulic Excavator Operator’s Manual 2023 – PDF DOWNLOAD

The Hyundai R480LC-9MH Hydraulic Excavator Operator’s Manual 2023 is a downloadable PDF guide for safe and efficient equipment operation. It provides essential information for operators, ensuring proper usage and optimizing the excavator’s performance.

FILE DETAILS:

Hyundai R480LC-9MH Hydraulic Excavator Operator’s Manual 2023 -PDF DOWNLOAD

Language : English
Pages : 220
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

Hyundai R480LC-9MH Hydraulic Excavator Operator’s Manual 2023 -PDF DOWNLOAD

CONTENTS 1
FOREWORD 2
BEFORE SERVICING THIS MACHINE 3
EC REGULATION APPROVED 4
TABLE TO ENTER SERIAL NO AND DISTRIBUTOR 6
SAFETY LABELS 7
MACHINE DATA PLATE 20
GUIDE 21
SAFETY HINTS 22
1 BEFORE OPERATING THE MACHINE 22
2 DURING OPERATING THE MACHINE 37
3 DURING MAINTENANCE 45
4 PARKING 48
SPECIFICATIONS 49
1 MAJOR COMPONENT 49
2 SPECIFICATIONS 51
3 WORKING RANGE 53
4 WEIGHT 55
5 LIFTING CAPACITIES 56
6 GRAPPLE 58
7 UNDERCARRIAGE 59
8 SPECIFICATIONS FOR MAJOR COMPONENTS 60
9 RECOMMENDED OILS 63
CONTROL DEVICES 64
1 CAB DEVICES 64
2 CLUSTER 65
3 SWITCHES 86
4 LEVERS AND PEDALS 91
5 AIR CONDITIONER AND HEATER 93
6 OTHERS 97
OPERATION 135
1 SUGGESTION FOR NEW MACHINE 135
2 CHECK BEFORE STARTING THE ENGINE 136
3 STARTING AND STOP THE ENGINE 137
4 MODE SELECTION SYSTEM 141
5 OPERATION OF THE ORKING DEVICE 146
6 TRAVELING OF THE MACHINE 147
7 EFFICIENT WORKING METHOD 150
8 OPERATION IN THE SPECIAL WORK SITES 152
9 NORMAL OPERATION OF EXCAVATOR 154
10 ATTACHMENT LOWERING (when engine is stopped) 155
11 STORAGE 156
12 OPERATION OF CAB (OPTION) 158
TRANSPORTATION 160
1 PREPARATION FOR TRANSPORTATION 160
2 DIMENSION AND WEIGHT 161
3 LOADING THE MACHINE 165
4 FIXING THE MACHINE 167
5 LOADING AND UNLOADING BY CRANE 168
6 DISASSEMBLE FOR TRANSPORTATION 169
MAINTENANCE 172
1 INSTRUCTION 172
2 TIGHTENING TORQUE 177
3 FUEL, COOLANT AND LUBRICANTS 180
4 MAINTENANCE CHECK LIST 182
5 MAINTENANCE CHART 187
6 SERVICE INSTRUCTION 189
7 ELECTRICAL SYSTEM 211
8 AIR CONDITIONER AND HEATER 214
TROUBLESHOOTING GUIDE 216
1 ENGINE 216
2 ELECTRICAL SYSTEM 217
3 OTHERS 218
INDEX 225

DESCRIPTION:

Hyundai R480LC-9MH Hydraulic Excavator Operator’s Manual 2023 -PDF DOWNLOAD

FOREWORD:

• This manual contains a number of instructions and safety recommendations regarding driving, han-
  dling, lubrication, maintenance, inspection and adjustment of the excavator.
• The manual is to promote safety maintenance and enhance machine performance.
• Keep this manual handy and have all personnel read it periodically.
• If you sell the machine, be sure to give this manual to the new owners. This machine complies with
  EC directive “2006/42/EC”.

1. Read and understand this manual before operating the machine.

• This operator’s manual may contain attachments and optional equipment that are not available in
  your area. Please consult your local Hyundai distributor for those items you require.
• Improper operation and maintenance of this machine can be hazardous and could result in serious
  injury or death.
• Some actions involved in operation and maintenance of the machine can cause a serious accident, if
  they are not done in a manner described in this manual.
• The procedures and precautions given in this manual apply only to intended uses of the machine. If
  you use your machine for any unintended uses that are not specifically prohibited, you must be sure
  that it is safe for you and others. In no event should you or others engage in prohibited uses of
  actions as described in this manual.

2. Inspect the jobsite and follow the safety recommendations in the safety hints section before
operating the machine.
3. Use genuine Hyundai spare parts for the replacement of parts.

• We expressly point out that Hyundai will not accept any responsibility for defects resulting from
  non- genuine parts or non workmanlike repair.
• In such cases Hyundai cannot assume liability for any damage.

Continuing improvements in the design of this machine can lead to changes in detail which may not
be reflected in this manual. Consult Hyundai or your Hyundai distributor for the latest available
infor- mation for your machine or for questions regarding information in this manual.
