John Deere 160GLC Excavator Parts Catalog Manual PDF DOWNLOAD

Starting from:

$45

Home

John Deere 160GLC Excavator Parts Catalog Manual - PDF DOWNLOAD

File Details:

John Deere 160GLC Excavator Parts Catalog Manual

Language : English
Pages : 972
Size : 71.5 MB
Downloadable : Yes
Format : PDF
Serial No : PC10253

Image Preview:

Description:

John Deere 160GLC Excavator Parts Catalog Manual

To The Customer
The part numbers in this Parts Catalog were correct at the time of publication. Per John Deere policy, we continuously improve our
products. Therefore, when ordering parts verify the part numbers with your dealer.
SI Units of Measure
Metric dimensions are provided as applicable throughout this parts catalog.
Bolt and Cap Screw Strength Identification
Bolts and cap screws required to have high-strength qualities equivalent to metric property class 10.9 (SAE grade 8) or higher are identified throughout this catalog by the description 10.9, 12.9 or 14.9. All standard bolts and cap screws are metric property class 8.8 (SAE grade 5) or lower.
Serial Number Listing Information
Serial number information is listed to show on which machines each part can be used; for example:
– The part can be used on all products.
000000 – The part can be used on products beginning with the serial number listed.
– 000000 The part can be used on products up to and including the serial number listed.
000000 – 000000 The part can be used on products between and including the serial number listed.
When XXXXXX’s are listed in place of a serial number, a serial number change was made, but the exact serial number was not available at the time of publication.
Direction Arrow
Arrows are used with illustrations to indicate the front of the unit. “Right-Hand” and “Left-Hand” sides are determined by facing in direction of machine forward travel.
Box-Enclosed Illustrations
Box-enclosed keyed parts in the illustration are available as a service assembly or an attachment. These parts may also include parts not available for service. The illustrations may not show all individual parts of an attachment. A box not keyed includes non-current parts.
Complete Goods Listings
Complete Goods are listed in bold face type. Order separately. Do not include on replacement part order.
Orientation of Engine
Right Hand (RH) and Left Hand (LH) sides are determined by standing at flywheel and facing the engine.
Orientation of Engine
Right Hand (RH) and Left Hand (LH) sides are determined by standing at flywheel and facing the engine.
John Deere Remanufactured Components
The REMAN parts listed in this catalog are intended for the repair or replacement of failed or worn original equipment components. John Deere Reman components are manufactured to stringent John Deere standards and produced to original John Deere specifications that incorporates the latest design and performance improvement updates.

01 Wheels & Tires & Tracks
0130 Track Systems 54
02 Axles, Differentials and Suspension Systems
0260 Axles, Differentials & Suspension System Hydraulics 74
04 Engine 4045HT065-RE556611 – RE538995
0400 Engine 4045HT065 92
04A Engine 4045HT065-RE557221
0400A Engine 4045HT065 236
04B Engine 4045HT075-RE556877
0400B Engine 4045HT075 368
05 Engine Auxiliary System
0505 Cold Weather Starting Aids 496
0510 Engine Cooling Systems 498
0520 Intake System 520
0530 External Exhaust Systems 526
0540 Engine Mounting 530
0560 External Fuel Supply Systems 532
13 Miscellaneous Vehicle
1311 Vehicle Assembly 538
1322 Labels & Trademarks 540
16 Vehicle Electrical Systems
1671 Batteries, Support & Cables 546
1673 Vehicle Lighting System 548
1674 Wiring Harness & Switches 560
17 Frame, Chassis, or Supporting Structure
1740 Frame Installation 588
18 Operator’s Station
1810 Operator Enclosure 596
1821 Seat And Seat Belts 648
1830 Heating & Air Conditioning 672
19 Sheet Metal and Styling
1910 Hood Or Engine Enclosure 688
20 Safety, Convenience, and Miscellaneous
2001 Radio 716
2002 Mirror 718
2004 Warning Devices Including Horn & Reverse Alarm 724
2010 Miscellaneous 730
21 Vehicle Main Hydraulic System
2161 Hydraulic Pumps & Drives 736
2162 Control Valves 748
2164 Hydraulic Reservoir, Filter & Cooler 772
26 Global Vehicle Communication
2601 Communication Controller 778
33 Backhoe & Excavator
3302 Bucket With Teeth 782
3315 Control Linkage 804
3340 Backhoe & Excavator Frames 828
3362 Control & Load Holding Valves 844
3363 Lines, Hoses & Fittings 846
3365 Hydraulic Cylinders 910
43 Swing, Rotation Or Pivoting System
4350 Mechanical Drive Elements 928
