John Deere 1720 and 1725 Planters TECHNICAL MANUAL - PDF DOWNLOAD

John Deere 1720 and 1725 Planters TECHNICAL MANUAL - PDF DOWNLOAD

FILE DETAILS:

John Deere 1720 and 1725 Planters TECHNICAL MANUAL - PDF DOWNLOAD

Language :English
Pages :156
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

DESCRIPTION:

John Deere 1720 and 1725 Planters TECHNICAL MANUAL - PDF DOWNLOAD

ExactEmerge™ and
MaxEmerge™ 5e
Performance Upgrade for
1720 and 1725 Planters

Introduction IMPORTANT:

Read this instruction thoroughly and familiarize yourself with the planter before performing this procedure

• This instruction covers installing the electric drive ExactEmerge™ or MaxEmerge™ 5e meter system on John Deere planters (2004—) with MaxEmerge™ XP or MaxEmerge™ 5 row units. Refer to your John Deere™ dealership for complete details.
• Right-hand and Left-hand sides are determined by facing in the direction of forward travel. A95278 — UN—23FEB17 ExactEmerge is a trademark of Deere & Company MaxEmerge is a trademark of Deere & Company

Safety Information

This is a safety-alert symbol. When you see this symbol on your machine or in this manual, be alert to the potential for personal injury. Follow recommended precautions and safe operating practices.

TABLE OF CONTENTS:

John Deere 1720 and 1725 Planters TECHNICAL MANUAL - PDF DOWNLOAD

ExactEmerge™ and
MaxEmerge™ 5e
Performance Upgrade for
1720 and 1725 Planters

Contents 11
Disassemble Planter 13
Remove Ground Drive Components 13
Remove Variable Rate Drive Components 14
Ground Drive Liquid Fertilizer (If Equipped) 17
Remove the Tail Lights 18
Remove Entire MaxEmerge™ XP Row Unit (ExactEmerge™ Performance Upgrade Only) 19
Remove MaxEmerge™ 5 Meter Components from Row Units (ExactEmerge™ Performance Upgrade Only) 25
Remove MaxEmerge™ XP Meter Components from Row Units (MaxEmerge™ 5e Performance Upgrade Only) 29
Remove MaxEmerge™ 5 Meter Components from Row Units (MaxEmerge™ 5e Performance Upgrade Only) 33
Remove Backbone Harnessing and Control Units 36
Planter Harnessing 38
Install 8-Row Harnesses 38
Install 12-Row Harnesses 42
Install 16-Row Harnesses 47
Install the Control Unit Assembly 52
Motion Sensor and Bracket 57
Install Tone Wheel 57
Install Motion Sensor on the Support 58
Install Motion Sensor on Wheel Arm 59
Planter Tail Lights 62
Install Tail Lights 62
Depth Adjustment Assembly for Depth Gauge Wheels 64
Disassemble Depth Adjustment Assembly for the Depth Gauge Wheels 64
Assemble the Depth Adjustment Assembly for the Depth Gauge Wheels 64
Assemble and Attach ExactEmerge™ Row Units 66
MaxEmerge™ XP to ExactEmerge™ Row Unit Conversion 66
MaxEmerge™ 5 to ExactEmerge™ Row Unit Conversion 86
Assemble and Attach MaxEmerge™ 5e Row Units 98
MaxEmerge™ XP to MaxEmerge™ 5e Row Unit Conversion 98
MaxEmerge™ 5 to MaxEmerge™ 5e Row Unit Conversion 110
3 bu Hopper Conversion for MaxEmerge™ XP Shank 120
Electric Drive Alignment 121
Tractor Power Generation 123
Lubricate the Tractor Power Generation System 123
Tractor Power Generation 123
Install the Tractor Power Generation System on 6175R, 6195R, and 6215R John Deere Tractors 124
Install the Tractor Power Generation System on 6170R, 6190R, and 6210R John Deere Tractors 131
Install the Tractor Power Generation System on 7R John Deere Tractors 138
Install the Tractor Power Generation System on 8R John Deere Tractors 143
Install the Tractor Power Generation System on Other Tractors 148
Remove the Tractor Power Generation System 153
Software Installation 155
Software Installation 155
