Foreword

Since this machine is large in size, it is divided into some units to meet the transportation conditions and regulations applied to the transporta­tion route when shipped from our factory. This manual describes how to assemble the units into the complete machine in the field. We hope that this machine will display its quality and you will use it safely according to the operation manual. Many units are large in size and heavy in weight and may be handled in a dangerous place or posture and many workers may have to work together to sling them with cranes. Accordingly, before starting the assembly work, the work supervisor is required to hold a safety meeting to oblige the workers to put on pro­ tective gear and appoint a work leader and a crane work signal man and allot roles to all the workers for safe work. In particular, the above meeting is more important when worker of dif­ferent languages and customs work together. The following is a reference supervision system diagram.

TABLE OF CONTENTS:

Komatsu HYDRAULIC EXCAVATOR PC750 -7 PC750SE-7 PC800 -7 PC750LC-7 PC800SE-7 Field Assembly Manual(GEN00014-04) – PDF DOWNLOAD

Cover………………………………………………………………………. 1
Foreword……………………………………………………………………. 3
Contents……………………………………………………………………. 5
Specifications………………………………………………………………. 7
Precautions for Field Assembly………………………………………………… 8
Disposal of Removed Parts…………………………………………………….. 9
Assembling Procedures, Applicable Equipment and Schedule…………………………. 10
Transportation………………………………………………………………. 12
Packing Style for Transportation………………………………………………. 12
List of Tools for Field Assembling…………………………………………….. 18
Tightening Torque……………………………………………………………. 19
Coating Materials List……………………………………………………….. 23
A. Assembling of Chassis……………………………………………………… 25
A-1 Installation of Left and Right Track Frames……………………………… 26
A-2 Installation of Travel Pipe……………………………………………. 29
A-3 Installation of Top Guard……………………………………………… 32
A-4 Installation of Radiator Cover…………………………………………. 33
A-5 Installation of Rearview Mirror………………………………………… 34
A-6 Installation of Handrail………………………………………………. 38
A-7 Installation of Step………………………………………………….. 41
A-8 Installation of Left Side Step…………………………………………. 42
A-9 Installation of Muffler Tail Tube………………………………………. 43
A-10 Sticking of Sheet (to Counterweight)…………………………………… 44
A-11 Installation of Counterweight…………………………………………. 45
A-12 Installation of ORBCOMM Antenna (if equipped)…………………………… 46
A-13 Installation of Step Light……………………………………………. 47
A-14 Installation of Travel Pipe Cover……………………………………… 49
A-15 Extension of Track Frame Gauge (Only when 3-split packages are tansported)…. 50
A-16 Testing Track Shoe Tension……………………………………………. 53
A-17 Inspection of Oil Amount ans Water Amount………………………………. 56
A-18 Parts to be Touched up After Field Assembly…………………………….. 58
B. Assembling of Work Equipment of Backhoe……………………………………… 59
B-1 Pulling Out of Boom Foot Pin, and Boom Cylinder Foot Pin………………….. 60
B-2 Installation of Boom Assembly………………………………………….. 61
B-3 Relieving Remaining Pressure from Hydraulic Circuit………………………. 62
B-4 Installation of Boom Cylinder Foot……………………………………… 63
B-5 Installation of Boom Cylinder Hose……………………………………… 64
B-6 Installation of Boom Cylinder………………………………………….. 65
B-7 Installation of Arm Cylinder…………………………………………… 66
B-8 Installation of Arm Cylinder Hose………………………………………. 67
B-9 Installation of Arm Assembly…………………………………………… 68
B-10 Installation of of Hose between Boom and Bucket Cylinder…………………. 70
B-11 Installation of Bucket Assembly……………………………………….. 71
B-12 Lubrication Piping to Work Equipment…………………………………… 72
B-13 Connection of Wiring of Work Equipment…………………………………. 73
B-14 Greasing after Assembling Work Equipment……………………………….. 74
B-15 Air Bleeding from Hydraulic Cylinder…………………………………… 75
C. Assembling of Work Equipment of Loading Shovel……………………………….. 77
C-1 Releasing residual pressure in hydraulic circuit…………………………. 78
C-2 Pulling out boom foot pin and boom cylinder foot pin……………………… 79
C-3 Installation of boom and arm assembly…………………………………… 80
C-4 Installation of flushing piping between chassis and boom………………….. 81
C-5 Installation of flushing piping for boom cylinder and arm cylinder…………. 82
C-6 Installation of flushing piping for bucket cylinder………………………. 83
C-7 Installation of flushing piping for bottom dump cylinder………………….. 84
C-8 Installation of boom cylinder………………………………………….. 86
C-9 Installation of boom cylinder foot……………………………………… 87
C-10 Installation of boom cylinder hoses……………………………………. 88
C-11 Installation of boom cylinder rod pin………………………………….. 89
C-12 Installation of arm cylinder hoses ……………………………………. 90
C-13 Installation of bucket cylinder……………………………………….. 91
C-14 Installation of bucket cylinder hose ………………………………….. 92
C-15 Installation of connecting hoses between chassis and boom top…………….. 93
C-16 Installation of bottom dump cylinder hose………………………………. 94
C-17 Installation of bucket assembly……………………………………….. 95
C-18 Installation of working lamps…………………………………………. 97
C-19 Installation of work equipment drease piping……………………………. 98
C-20 Greasing after assembling of work equipment…………………………….. 99
C-21 Bleeding air from work equipment circuit………………………………..100
M. Procedure for Inspection and Maintenance after Completion of Assembly……………101
M-1 Inspection of Oil level in Hydraulic Tank and Refill………………………102
M-2 Replacement of Return Filter (Standard Filter to Flushing Filter)…………..104
M-3 Flushing of Hydraulic Circuit…………………………………………..105
M-4 Replacement of Return Filter (Flushing Filter to Standard Filter)…………..107
Field Assembly Inspection Report (Backhoe)………………………………………109
Field Assembly Inspection Report (Loading Shovel)………………………………..135
