DESCRIPTION:

SERIAL NUMBERS PC5500-6 15031,15035 & UP

Komatsu HYDRAULIC MINING SHOVEL PC5500-6 Operation & Maintenance Manual(SMPC550015035) – PDF DOWNLOAD

SAFETY
SAFETY NOTICE
• IMPORTANT SAFETY NOTICE
Proper service and repair is extremely important for safe machine operation. The
service and repair techniques recommended by Komatsu and described in this manual
are both effective and safe. Some of these techniques require the use of tools specially
designed by Komatsu for the specific purpose.
The following Symbols are used in this Manual to designate Instructions of
particular Importance.

WARNING – Serious personal injury or extensive property damage can
result if the warning instructions are not followed.
To prevent injury to workers, this symbol is used to mark
safety precautions in this manual. The cautions
accompanying these symbols should always be followed
carefully. If any dangerous situation arises or may possibly
arise, first consider safety, and take the necessary actions to
deal with the situation.
CAUTION – Minor personal injury can result or a part, an assembly, or
the shovel can be damaged if the caution instructions are not
followed.
NOTE – Refers to special information
GENERAL PRECAUTIONS
Mistakes in operation are extremely dangerous. Read the OPERATION & MAINTENANCE
MANUAL carefully BEFORE operating the machine.
1. Before carrying out any greasing or repairs, read all the precautions given on the decals
which are fixed to the machine.
2. When carrying out any operation, always wear safety shoes and helmet. Do not wear
loose work clothes, or clothes with buttons missing.
• Always wear safety glasses when hitting parts with a hammer.
• Always wear safety glasses when grinding parts with a grinder, etc.
TABLE OF CONTENTS:

Komatsu HYDRAULIC MINING SHOVEL PC5500-6 Operation & Maintenance Manual(SMPC550015035) – PDF DOWNLOAD

00 Safety – Foreword
01 Technical DATA (Leaflet)
02 Assembly PROCEDURE (Brochure)
Section
1. Main assembly groups
2. Drive.
3. Hydraulic oil tank.
4. Hydraulic oil cooling.
5. Controlling.
6. Components
7. Main hydraulic pumps and pump regulation.
8. Operating hydraulic.
9. Hydraulic track tensioning system.
10. Hydraulic operated access ladder
11.Refilling Arms
12. Hints for the hydraulic circuit diagram
13. Hints for the electric circuit diagram
14. ECS-T
15. Lubrication Systems

IMAGES PREVIEW OF THE MANUAL:
