New Holland 300FP, 380FP Header Service Repair Manual (47998488)

New Holland 300FP, 380FP Header Service Repair Manual (47998488)

FILE DETAILS:

New Holland 300FP, 380FP Header Service Repair Manual (47998488)

• Item Number:47998488
• Description:300FP, 380 FP Header from PIN 3501
• Language:English
• Type:Service Manual
• P.I.N.:from PIN 3501
• Model:300FP, 380FP
• IMAGES PREVIEW FROM THE MANUAL:

DESCRIPTION:

New Holland 300FP, 380FP Header Service Repair Manual (47998488)

• This manual has been produced by a new technical information system. This new system is designed to deliver technical information electronically through Web delivery (eTim), DVD and in paper manuals. A coding system called SAP has been developed to link the technical information to other Product Support functions, e.g., Warranty.
• Technical information is written to support the maintenance and service of the functions or systems on a customer’s machine. When a customer has a concern on his machine it is usually because a function or system on his machine is not working at all, is not working efficiently, or is not responding correctly to his commands. When you refer to the technical information in this manual to resolve that customer’s concern, you will find all the information classified using the SAP coding, according to the functions or systems on that machine.
• Once you have located the technical information for that function or system then you will find all the mechanical, electrical or hydraulic devices, components, assemblies and sub assemblies for that function or system.
• You will also find all the types of information that have been written for that function or system, the technical data (specifications), the functional data (how it works), the diagnostic data (fault codes and troubleshooting) and the service data (remove, install adjust, etc.).
• By integrating SAP coding into technical information, you will be able to search and retrieve just the right piece of technical information you need to resolve that customer’s concern on his machine. This is made possible by attaching 3 categories to each piece of technical information during the authoring process.
• All repair and maintenance work listed in this manual must be carried out only by qualified dealership personnel, strictly complying with the instructions given, and using, whenever possible, the special tools.
• Anyone who performs repair and maintenance operations without complying with the procedures provided herein shall be responsible for any subsequent damages.
• The manufacturer and all the organizations of its distribution chain, including – without limitation – national, regional, or local dealers, reject any responsibility for damages caused by parts and/or components not approved by the manufacturer, including those used for the servicing or repair of the product manufactured or marketed by the manufacturer.
• In any case, no warranty is given or attributed on the product manufactured or marketed by the manufacturer in case of damages caused by parts and/or components not approved by the manufacturer.
• The manufacturer reserves the right to make improvements in design and changes in specifications at any time without notice and without incurring any obligation to install them on units previously sold. Specifications, descriptions, and illustrative material herein are as accurate as known at time of publication but are subject to change without notice.
• In case of questions, refer to your NEW HOLLAND CONSTRUCTION Sales and Service Networks.

TABLE OF CONTENTS:

New Holland 300FP, 380FP Header Service Repair Manual (47998488)

INTRODUCTION
Hydraulic systems…………………………………………………………….. 35
[35.000] Hydraulic systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35.1
[35.359] Main control valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35.2
[35.560] Pickup lift circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35.3
[35.661] Grass pickup drive system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35.4
Electrical systems …………………………………………………………….. 55
[55.000] Electrical system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55.1
[55.100] Harnesses and connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55.2
Attachments/Headers………………………………………………………… 58
[58.120] Attachment/Header feed auger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58.1
[58.900] Belt feeding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58.2
Product feeding ……………………………………………………………….. 60
[60.220] Pickup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60.1
