DESCRIPTION:

New Holland FIAT Trattori 115-90 130-90 140-90 160-90 180-90 Turbo Service Manual

• The manual is divided into separately numbered sections.
• Two-digit sections whose second digit is zero contain:
• — tractor specification (00)
• — tractor sub-assembly specification and data (10-Engine; 20-Power Train; 30-Front
• Axle-Steering; 40-Front Wheel Drive; 50-Hydraulic Lift Unit; 60-Electrical System;
• 90-Service Tools).
• Two-digit sections whose second digit is from one to nine deal with overhaul of the sub-assemblies whose data are listed in the sections described above.
• The first digit is the same as that of the corresponding data section (e. g. 20 – Power
• Train, is associated with 22 – Clutch; 23 – Transmission and Splitter; 24 – Creeper,
• Mechanical Reverse 3 etc… ).
• A contents list is provided to facilitate retrieval of desired information.
• The print number of the manual and the date of issue is shown at the bottom of each page.
• Revised sheets will carry the same print number followed by a two-digit number (e.g. first revision 603.54.252.01; second revision 603.54.252.02; etc.) and date of issue.
• Revised sheets will be accompanied by the updated contents sheet.
• All information herein is correct at the time of printing but is subject to alteration without prior notice in case of discrepancies contact the nearest dealer, distributor of branch.
