New Holland Ford Automatic Bale Wagon 1068 1069 & 1075 Round Bale Wagon 8500 Service Manual (40106841)

• This service manual provides the technical information needed to properly service New Holland self-propelled automatic halo wagons. Use this manual in conjunction with the operator’s manual supplied with bale wagon.
• This manual details the procedures for removal. disassembly. and reassembly that have been found to be the easiest and least time-consuming. There may be several ways oi completing a job. but generally the methods described are best.
• 0n Ford New Holland equipment. left and right are determined by standing behind the unit. looking in the direction at travel.
• Certain hardware on self-propelled bale wagons must be tightened to particular torque specifications. ll specific torque specifications are not noted, tighten the hardware to the standard torque chart specification listed in this manual.
• The descriptions and specifications contained in this manual were in cffecl at the time the book was released for printing. Ford New Holland. Int; reserves the right to ciscentinuc models atanytime. orto change specifications and design without notice and without ircurring obligation.

Table of Contents:

New Holland Ford Automatic Bale Wagon 1068 1069 & 1075 Round Bale Wagon 8500 Service Manual (40106841)

Table of Contents
..................................  3
Air-Conditioner
...................................  7
Power Steering Gear
................................ 15
Steering Linkage and Front Axle Specifications
 .... 47
Brakes
............................................. 53
Clutch
............................................. 83
Transmission
....................................... 95
Drive Axle
.........................................133
Hydraulic System
...................................179
Charging System
....................................223
