Starting from:
$45
New Holland TS90,TS100,TS110,TS115 Tractors Service Repair Manual (86572172)
New Holland TS90,TS100,TS110,TS115 Tractors Service Repair Manual (86572172)
FILE DETAILS:
New Holland TS90,TS100,TS110,TS115 Tractors Service Repair Manual (86572172)
- Format: PDF
- Language: English
- Number of Pages: 1815 pages
- Brand: New Holland
- Type of document: Service Manual
- Model: TS100, TS110, TS115, TS90
- Part No: 86572172
- IMAGE PREVIEW:
SAMPLE PAGE FROM THE MANUAL:
New Holland TS90,TS100,TS110,TS115 Tractors Service Repair Manual (86572172)
- The function of the air conditioning system is to improve tho operator’s oomlort by cooling the air temperature inside the cab and reducing the humidity level.
- This temperature control is achieved by absorbing the heat within the cab into a refrigerant and than allowing the heat absorbed by the refrigerant to be transferred to the outside air In order to achieve this heat transfer the following principals of heat generation and transfer are applied within the air conditioning system.
- When two bodies of different temperature come together heat is transferred from one to another. On air conditioning systems an evaporator is used to hold the low temperature refrigerant which absorbs the heat from the air within the cab.
- When a gas ls pressurised the temperature of the gas will rise. In air conditioning systems the increase in pressure is achieved using a compressor.
- When a gas is cooled it will condense into a liquid. In the air conditioning system a condenser is used to cool the gas and the resulting liquid is stored in a receiver dryer.
- When a liquid is atomized through an orifice, the temperature of the resonant vapour will drop. The low temperature of the atomized liquid erI then absorb heat from its surroundings. On air conditioning systems the refrigerant is atomized using an expansion valve.
TABLE OF CONTENTS:
New Holland TS90,TS100,TS110,TS115 Tractors Service Repair Manual (86572172)
SECTION 1 — GENERAL INFORMATION
SECTION 2 — ENGINE
SECTION 3 — ELECTRICAL SYSTEM
SECTION 4 — HYDRAULIC SYSTEMS
SECTION 5 — BRAKING AND STEERING SYSTEMS
SECTION 6 — POWER TRAIN
SECTION 7 — FRONT AXLE
SECTION 8 — POWER TAKE OFF
SECTION 9 — AIR CONDITIONING
SECTION 10 — SPECIAL TOOLS
