Sakai TW320-1 TW330-1 Operation & Maintenance Manual Serials 40101-40103 PDF

Sakai Vibrating Roller TW320-1 TW330-1 Operation & Maintenance Manual – PDF DOWNLOAD

The Sakai Vibrating Roller TW320-1 TW330-1 Operation & Maintenance Manual is a comprehensive guide in PDF format detailing procedures for operating and maintaining Sakai’s TW320-1 and TW330-1 vibrating rollers, aiding users in efficient equipment utilization and upkeep.

FILE DETAILS:

Sakai Vibrating Roller TW320-1 TW330-1 Operation & Maintenance Manual – PDF DOWNLOAD

Language : English
Pages : 89
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

DESCRIPTION:

Sakai Vibrating Roller TW320-1 TW330-1 Operation & Maintenance Manual – PDF DOWNLOAD

• This operator’s manual serves as a guide for the use of your Sakai TW320-1 ,TW330-1 Vibrating Roller for those who are new to the machine, and also for the people who have experience in using the Machine and want to refresh their knowledge for the machine.
• Read this manual thoroughly and try to fully understand the information before operating your machine. Keep this handbook at hand whenever you do your work.
  The main subjects of this manual are:
  (1) Basic precautions for safety, (2) Operation, (3) Daily maintenance and (4) Specifications.
• For operation and maintenance of the engine, refer to the Engine Instruction Manual furnished separately. Descriptions in this manual can differ from the machine instructions of your machine due to the results of the investigation and improvement in its design. If you have any inquiry regarding your Machine or this manual, contact our distributors.

TABLE OF CONTENTS:

Sakai Vibrating Roller TW320-1 TW330-1 Operation & Maintenance Manual – PDF DOWNLOAD

PREFACE
MACHINE AND ENGINE IDENTIFICATION NUMBERS 1
SAFETY NOTICES 2
1. BASIC PRECAUTIONS FOR SAFETY
1.1 General Precautions 4
1.2 Preparation for Safe Operation 6
1 3 Before Starting the Engine 7
1.4 After Starting the Engine 8
1. 5 Du ring operation , 8
1.6 Loading and Unloading 1 O
1.7 Transportation 11
1.8 Handling the Battery 11
1.9 Towing 12
1.10 Before Servicing 13
1.11 During Servicing 14
1.12 Safety Decals 16
2. OPERATION
2.1 Instruments and Controls 18
2.1.1 Operator’s station 18
2.1.2 Gauges, indicator lamps and warning lamps 19
2.1.3 Switches 21
2.1.4 Operating levers and pedals 24
2.1.5 Fuse box : 25
2.2 Handling and Adjustments 25
2.2.1 Seat adjustment. 25
2.2.2 Scraper adjustment and replacement 26
2.2.3 Disengaging the brake when towing 27
2.3 Operation 28
2.3.1 Before-starting inspect.ion 28
2.3.2 Starting the engine 29
2.3.3 After starting the engine -30
2.3.4 Traveling 31
2.3.5 Stopping / Parking 32
2.3.6 Stopping the Engine 33
2.3.7 Check after Stopping the Engine 33
2.4 Vibratory Operation 34
2.5 Sprinkler 35
2.6 Liquid Sprayer 38
2. 7 Precautions for Work 39
2.7.1 Compaction operation 39
2.7.2 When going downhill 39
2.7.3 On a slope 39
2.8 Applicable Jobs 40
2.9 After Operation 40
2.10 Loading and Unloading 41
2.10.1 Use of a trailer equipped with a winch 41
2.10.2 Self-propelling 42
2.10.3 Use of a hoist. 43
2.11 After Loading the Machine 44
2.12 Transportation 44
2.13 Operation in Cold Weather 44
2.13.1 Fuel oil and grease 4 4
2.13.2 Coolant 45
2.13.3 Battery 46
2.14 When the Cold Season is Over 46
2.15 For a Long Storage Period 4 7
2.16 During the Storage Period 4 7
2.17 When the Battery Has Discharged 48
2.17 1 Connection and disconnection of booster cables 49
3. PERIODICAL MAINTENANCE
3.1 Precautions : 50
3.2 Walk-Around Checking 52
3.2.1 Tire inflation pressure check 53
3.2.2 Checking for exter_nal injury to a tire 54
3.3 Periodical Maintenance Points 55
3.4 Maintenance Procedure 58
(1) Every 10 hours or daily 58
(2) Every 100 hours 60
(3) Every 200 hours 60
(4) Every 250 hours 61
(5) Every 450 hours 61
(6) Every 500 hours 61
(7) Every 1000 hours 63
(8) As required 73
3.5 Consumable Parts 77
3.6 Feeding Water and Lubricants 78
3.7 Electric Wiring Diagram 80
4. SPECIFICATIONS 82
