Sakai Vibrating Roller SW884 SW884ND SW994 SW994ND OPERATING & MAINTENANCE Manual

Sakai Vibrating Roller SW884 SW884ND SW994 SW994ND OPERATING & MAINTENANCE MANUAL- PDF DOWNLOAD

FILE DETAILS:

Sakai Vibrating Roller SW884 SW884ND SW994 SW994ND OPERATING & MAINTENANCE MANUAL- PDF DOWNLOAD

Language : English
Pages :148
Downloadable : Yes
File Type : PDF

TABLE OF CONTENTS:

Sakai Vibrating Roller SW884 SW884ND SW994 SW994ND OPERATING & MAINTENANCE MANUAL- PDF DOWNLOAD

CONTENTS
PREFACE
MACHINE AND ENGINE IDENTIFICATION NUMBERS 1
SAFETY NOTICES 2
1 BASIC PRECAUTIONS FOR SAFETY 4
11 General Precautions 4
12 Preparation for Safe Operation 8
13 Before Starting the Engine 9
14 After Starting the Engine 11
15 During Operation 12
16 Loading and Unloading 16
17 Transportation 16
18 Handling the Battery 17
19 Towing 18
110 Before Servicing 19
111 During Servicing 21
112 Safety Decals 24
2 OPERATION 26
21 Instruments and Controls 26
211 Operator’s station 26
212 Gauges, indicator lamps and warning lamps 27
213 Switches 33
214 Operating levers / pedals 41
215 Fuse box and line fuse 43
22 Handling and Adjustments 43
221 Seat adjustment 43
222 Accessory socket 44
223 Scraper adjustment and replacement 45
224 Disengaging the brake when towing 46
225 Steering wheel position adjustment 47
226 Operator’s platform position adjustment 47
227 Step for maintenance of engine room 48
228 Engine troubleshooting 48
23 Operation 49
231 Before-starting inspection 49
232 Starting the engine 50
233 After starting the engine 52
234 Traveling 52
235 Stopping and parking 56
236 AUTO SPEED 57
2361 Setting 57
2362 Canceling AUTO SPEED 58
237 Stopping the engine 59
238 Check after stopping the engine 59
24 Vibratory Operation 60
25 Operating the DEF SCR System 63
26 Water Spray System 68
27 EXACT COMPACT Operation (Impact Space Indicator & Speed Meter) 71
271 Function 71
272 Operating instruction 71
273 Operation 73
28 Machine Controller Diagnoses 73
29 Precautions for Work 75
291 Compaction operation 75
292 When going downhill 75
293 On a slope 75
210 Applicable Jobs 75
211 After Operation 76
212 Loading and Unloading 77
2121 Use of a trailer equipped with a winch 77
2122 Self-propelling 78
213 After Loading the Machine 78
214 Transportation 79
215 Operation in Cold Weather 79
2151 Fuel oil and grease 79
2152 Coolant 79
2153 DEF 80
2154 Battery 81
216 When the Cold Season is Over 82
217 For a Long Storage Period 82
218 During the Storage Period 83
219 When the Battery has Discharged 84
2191 Connection and disconnection of booster cables 84
3 PERIODIC MAINTENANCE 86
31 Precautions 86
311 Lifting the machine by hoist 88
32 Walk-around Checking 89
33 Periodic Maintenance Points 90
34 Maintenance Procedure 92
(1) Every 10 service hours or daily 92
(2) Every 50 service hours 94
(3) Every 250 service hours 95
(4) Every 500 service hours 97
(5) Every 1000 service hours 98
(6) Every 4000 service hours 104
(7) As needed 105
35 Consumable Parts 108
351 Changing the DEF pump filter 110
36 Fluid and Lubricant Capacities 111
37 Electric Wiring Diagram 114
38 Fuse Box and Line Fuse 117
39 Battery 117
4 SPECIFICATIONS 119
(1) SW884 119
(2) SW884ND 120
(3) SW994 121
_J L
